Application  No.C103
    News

            n Analysis of Wheat
            Fig. 3 describes the sample pretreatment procedure for   value), respectively. No large contaminant peaks were
            wheat. The wheat extract solution was purified using   detected in the chromatograms of the pretreated
            either the MultiSep #227 multi-function column (Romer   samples. Furthermore, although deoxynivalenol was
            Labs) or the Autoprep MF-T column (Showa Denko     detected, it was at a level below that of the provisional
            K.K.). The chromatograms generated using the samples   reference value. The spike-and-recovery rates for the
            prepared using the MultiSep #227 (unspiked samples)   four components were excellent, from 101 to 107 %,
            and the standard-spiked samples, respectively, are   without any particular matrix effects. Even in samples
            shown in Fig. 4. The standard mixture was added to   pretreated using Autoprep MF-T, comparable spike-
            obtain a final concentration of 25 ppb for the four   and-recovery test results were obtained.
            components (about 1/40 of the provisional reference




                         Wheat                                    Intensity              Intensity
                                                                                         (×10,000)
                                                                  (×1,000)
                                                                   1:371.05>281.20(-)  1.50  2:355.10>59.00(-)
                                                                   a)    Nivalenol         b)  Deoxynivalenol
                   Grind to less than 1000 µm                   7.5                    1.25
                                                                                       1.00
                                                                5.0                    0.75
                         50.0 g
                                                                                       0.50
                              200 mL Water/Acetonitrile=15/85(v/v)  2.5
                                                                                       0.25
                     Shake for 30 min                           0.0                    0.00
                                                                  1.5  2.0   2.5  min            3.0     3.5min
              Vacuum Filtration by Whatman GF/B                     Spike and Recovery 101 %  Spike and Recovery 107 %
                                                                  Intensity               Intensity
                                                                  (×10,000)               (×10,000)
                         15 mL                                     4:397.10 > 59.00(-)    3:397.10 > 59.00(-)
                                                                3.0                     3.0        3-Acetyl
                                                                   c)                      d)
                                                                                                   Deoxynivalenol
              Clean-up by multi function column                 2.0  15-Acetyl          2.0
                                                                   Deoxynivalenol
              “ MultiSep#227” or “Autoprep MF-T”
                               Discard the first 3 mL of solution.
                               Extract the next 5 mL of solution.   1.0                 1.0
                         4 mL
                                                                0.0                     0.0
                Evaporate by N2 gas below 45 ˚C
                                                                   4.0     4.5   min       4.0    4.5    min

                               1 mL Water/Acetonitrile/Methanol     Spike and Recovery 103 %  Spike and Recovery 104 %
                                       =90/5/5(v/v/v)
                        Filtration
                                                                Fig. 4  Chromatograms of Wheat
                                                                     (Dotted line: Unspiked Sample, Solid line: Spiked Sample,
                      Sample solution                                Spiked at 25 ppb each)
                                                                     a) Nivalenol  b) Deoxynivalenol
                                                                     c) 15-Acetyldeoxynivalenol  d) 3-Acetyldeoxynivalenol
                            Fig. 3  Pretreatment

                                                  Table 2  Analytical Conditions
              Column             : Shim-pack XR-ODS Ⅲ (150 mm L. × 2.0 mm I.D., 2.2 µm)
              Mobile Phases      : A 0.5 mmol/L Ammonium Acetate - Water
                                 : B Acetonitrile
              Time Program       : 5 %B (0 min) → 45 %B (5.0 min) → 95 %B (5.01-7.0 min) → 5 %B (7.01 min) → STOP (12 min)
              Flowrate           : 0.3 mL/min
              Column Temperature   : 40 ˚C
              Injection Volume   : 2 µL
              Probe Voltage      : -3.0 kV (ESI-negative mode)
              DL Temperature     : 100 ˚C
              Block Heater Temperature   : 200 ˚C
              Interface Temperature   : 200 ˚C
              Nebulizing Gas Flow   : 2 L/min
              Drying Gas Flow    : 10 L/min
              Heating Gas Flow   : 10 L/min
              MRM Transition     : Nivalenol        371.05 > 281.20   CE: 16.0 V
                                 : Deoxynivalenol   355.10 > 59.00   CE: 22.0 V
                                 : 15-Acetyldeoxynivalenol   397.10 > 59.00    CE: 22.0 V
                                 : 3-Acetyldeoxynivalenol   397.10 > 59.00    CE: 26.0 V

                                                                                                      First Edition: Apr. 2015
