P. 16

LAAN-A-LM-E107







            Application                  Liquid Chromatography Mass Spectrometry

            News                         Expanding Capabilities in Multi-Residue

                                         Pesticide Analysis Using The LCMS-8060
            No.C136                      David R. Baker , Laëtitia Fages , Eric Capodanno , Neil Loftus 1
                                                                    2
                                                      1
                                                                                   2
                                         1
                                         Shimadzu Corporation, UK;  Phytocontrol, France
                                                                  2
            n Abstract                                         was quickly and efficiently set up using the Shimadzu
            With an increasing global population, food security is   Pesticide MRM Library. For each target pesticide
            increasingly under threat and there is a growing   analysis, up to 3 MRMs (Multiple Reaction
            challenge for agriculture to produce more food, safely   Monitoring) transitions were imported from the
            and more sustainably. The use of herbicides,       library. 3 MRMs transitions provided additional data
            insecticides, and fungicides reduce crop losses both   confidence in reporting results in comparison to the
            before and after harvest, and increase crop yields.   conventional 2 transitions used in most methods. As
            However, pesticide residues resulting from the use of   the LCMS-8060 has a high data acquisition speed
            plant protection products on crops may pose a risk to   1,919 transitions were acquired using a polarity
            human health and require a legislative framework to   switching speed of 5 msec over a 10.5 minutes
            monitor pesticide residues in food.                gradient elution.
            National programs for pesticide monitoring in the US,   To evaluate the method QuEChERS extracts of mint,
            Europe and Japan have set Maximum Residue Levels   tomato and apple were provided by a commercial
            (MRL’s) or tolerance information (EPA) for pesticides in   laboratory as raw acetonitrile extracts and spiked
            food products. A default value of 0.01 mg/kg is applied   with 646 pesticides (data is presented on the mint
            for MRL enforcement, which therefore requires highly   extract as it is the more complex sample matrix). The
            sensitive and specific analytical technologies to monitor   method was evaluated in matrix to ensure that the
            an increasing number of pesticides.                reporting limits were in agreement with recognised
            This application note describes the expanded capability   MRL’s.
            of the LCMS-8060 to help accelerate method         n Experiment
            development workflows and support increased
            pesticide monitoring programs. Using the Shimadzu   Food extracts of mint, tomato and apple were
            Pesticide MRM Library (the Library includes information   supplied by Phytocontrol, France, following
            on 766 certified reference materials) a single multi-  established QuEChERS protocols. Final extracts were
            residue LC/MS/MS method was developed for 646      prepared in acetonitrile without any dilution.
            pesticides (3 MRM transitions for over 99 % targeted   Certified reference materials for the Shimadzu
            pesticides resulting in 1,919 transitions in total, with a   Pesticide MRM Library were obtained from ACSD,
            polarity switching time of 5 msec).                France as stock solutions. All solvents were of LCMS
                                                               quality purchased from Sigma-Aldrich.
            Keywords: Pesticides; food safety; LCMS-8060;      A six point calibration curve from 0.002 - 0.1 mg/kg
                      Pesticide MRM Library, 776 compound      (2 - 100 pg/μL) were generated using internal
                      library                                  standard   method.   Two   inter nal   standards
                                                               (Atrazine-d5 and Diuron-d6) were spiked in during
            n Introduction                                     the auto-sampler sequence for quantitation.
            There are more than 1,000 pesticides used globally   The robustness of the LCMS-8060 was assessed by
            on soil and crops. W ith the ever increasing       peak area response for 646 pesticides spiked into
            international trade of the food industry, regulatory   mint, tomato and apple matrix extracts at 0.05 mg/kg.
            bodies around the world have increased the number   n LC/MS/MS method development
            of regulated pesticides and the maximum residue
            levels (MRLs) allowed in food commodities. In the EU,   The Shimadzu Pesticide MRM Library has 766 pesticides
            regulation 396/2005/EC and its annexes set MRLs for   in its database (Application News No. C135). For each
            over 500 pesticides in 370 food products.  In the US,   pesticide several MRM’s are included in the database
                                                1)
            tolerances for more than 450 pesticides and other   and in this analysis the default value used was 3
                                                    2)
            ingredients are established by the US EPA  and     MRM’s. For this method, 1,919 transitions were
            Japan’s positive list system for agricultural chemical   selected in both positive and negative ionisation mode
            residues in foods contains MRLs for over 400       using a switching time of 5 msec (1,819 MRM
            pesticides in various commodities. 3)              transitions were in positive mode and 100 MRM
            National pesticide monitoring programs create new   transitions in negative mode).
            challenges for food safety laboratories as the number   To optimize ion source conditions (for example, DL
            of pesticides required for analysis is increasing   temperature, interface temperature, heating block
            together with an expanded range of food products.   temperature, heating gas flow, drying gas flow and
            In this application paper we present the development   nebulizer gas flow) the interface setting software was
            of a LC-MS/MS method for screening and quantifying   used. This tool provides an optimized response for all
            over 646 pesticides in a single method. The method   compounds.
