Page 30 - 2023 Shimadzu Analytical and Measuring Instruments
P. 30

MALDI-Based Instruments



            Benchtop Linear MALDI-TOF Mass Spectrometer          Dual-Polarity Benchtop Linear MALDI-TOF Mass Spectrometer
            MALDI-8020                                           MALDI-8030

















    Mass Spectrometry Systems
            The MALDI-8020 is a compact (width of main unit 60 cm) and   The MALDI-8030 expands on the successful benchtop format of the
            lightweight (weight of main unit 86 kg) table-top linear mode MALDI-  existing MALDI-8020 MALDI-TOF mass spectrometer, to offer positive-
            TOF instrument, it nonetheless achieves superior resolution and   ion and negative-ion analysis in the same footprint as the MALDI-8020.
            sensitivity. Moreover, longevity has been enhanced due to adoption of a   Instrument performance will mirror that of the MALDI-8020, with the
            solid-state laser, and it is equipped with TrueClean, an automatic ion   performance specifications of the MALDI-8020 extended to cater for
            source cleaning function. As a result, downtime is reduced to a   compounds best suited to analysis in negative ion mode. The benchtop
            minimum and maintenance costs can be reduced. It is readily capable of   system will offer a compact footprint, small enough for installation in
            delivering the performance needed for measurements for QC and   any lab. The versatile system will be applicable to a wide range of
            profiling applications that target peptides, proteins, polymers,   analytes, including proteins, peptides, oligonucleotides, lipids, glycans,
            oligonucleic acids, etc.                             polymers and small molecules.
             Mass range  m/z 1 to 500,000                        Mass range  m/z 1 to 500,000
             Mass resolution  > 5,000 FWHM                       Mass resolution  > 5,000 FWHM
             Mass accuracy  < 20 ppm (internal standard), < 150 ppm (external standard)  Mass accuracy  < 20 ppm (internal standard), < 150 ppm (external standard)
             Laser      Solid-state laser (355 nm)               Laser       Solid-state laser (355 nm)
                        Pulse rate: 50, 100, 200 Hz (variable)               Pulse rate: 50, 100, 200 Hz (variable)
                                                  Brochure No. MO432                                   Brochure No. MO473
            MALDI-TOF Mass Spectrometer                          Imaging Application Solution for MALDI-8020, MALDI-8030
            MALDI-7090                                           Benchtop MALDI-TOF Imaging Starter Kit  New



















            This high performance flagship model achieves high speed measurement   The MALDI-TOF Imaging Starter Kit provides a complete MALDI imaging
            (MS, MS/MS) at up to 2 kHz, and high MS/MS resolution (10,000) via   application solution for existing Shimadzu MALDI-8020 and MALDI-8030
            ASDF*. Thanks to truly high energy CID-MS/MS, this system maximizes   benchtop MALDI-TOF instruments, expanding the already versatile
            structural data for a variety of samples including biologically active   capabilities of these systems. The kit contains everything a user needs to
            substances and industrial materials. In addition, this system can flexibly   begin imaging experiments on their MALDI-8020 or MALDI-8030,
            accommodate a wide range of needs with its unique functionality,   including custom ITO-coated glass slides, a new custom glass slide
            including a laser beam diameter-changing mechanism suited to imaging   holder, the MALDI Solutions Imaging license enabling MALDI Imaging
            mass analysis; a sample loader with a 10 plate capacity, providing strong   acquisitions, and IonView imaging viewing software.
            support for LC-MALDI; and multi-user compatibility.                                        Brochure No. MO491
                        Linear mode  1 to 500,000 Da
             Mass range
                        Reflectron mode  1 to 70,000 Da
                        Linear mode  6,000
             Mass resolution  Reflectron mode  25,000
                        MS/MS       10,000
             MS/MS function         CID/PSD
             Mass accuracy  Reflectron mode  2 ppm (internal standard)
            * ASDF: Axial Spatial Distribution Focussing
      30                                          Brochure No. MO363
