Nucleic Acids and Proteins Analyzers
                                                                                        UV-VIS-NIR Spectrophotometers



          Protein Sequencer                                   Spectrophotometer for Life Science
          PPSQ-51A/53A                                        BioSpec-nano                                             Chromatography Systems

















                                         PPSQ-53A  Gradient System                                                     Mass Spectrometry Systems
          The PPSQ is an instrument for determining the amino acid sequences of   Capable of performing quantitation and purity checking of nucleic acids,
          proteins and peptides, which combines an Edman reaction section with   quantitation of proteins, and photometric measurements. Simply drop 1 to 2 µL of
          a high performance liquid chromatograph (HPLC).     the sample onto the measurement window and press the instrument's Start button
          There are 2 types: the PPSQ-51A, which is equipped with one reactor,   (or click the Start Measurement button in the software window), and all steps in   Life Science Lab Systems
          and the PPSQ-53A, which is equipped with three reactors. On the PPSQ-  the process, from setting the optical path length, measurement, up until the task
          53A, the continuous analysis of the amino acid sequences of multiple   of wiping off the sample from the measurement window, are all carried out
          samples can be performed one after another.         automatically. Troublesome work of moving arm up and down and wiping the
          In the Edman reaction section, amino acids are cleaved in order from   sample from the measurement window now unnecessary. Moreover, when using
          the N-terminal of a protein by repeatedly performing Edman   the specialized software, all it takes to perform a measurement, output a report,
          degradation, and are derivatized. As a result, stable PTH-amino acids are   export data, or carry out other common tasks is to click buttons on the toolbar.
          produced. The PTH-amino acids are injected online into the HPLC, and   Optical path length  0.2 mm, 0.7 mm (switched manually)
          analysis is performed. The HPLC data is saved on the PC, and data   Sample volume  Optical path length 0.2 mm: 1 µL or more,   Spectroscopy Systems
          processing software is used to process the chromatograms. Then, amino   Wavelength range  Optical path length 0.7 mm: 2 µL or more
                                                                           220 to 800 nm
          acid sequence estimation software is used to identify the amino acids   Wavelength accuracy  ±1 nm
          and estimate the sequences.                                                             Brochure No. C101-E112
                                             Brochure No. C297-E109
          UV-VIS Spectrophotometer                            UV-VIS Spectrophotometer
          UV-1280                                             UV-1900i                                                Systems  X-ray and Surface   Analysis



















          In addition to spectral measurements and quantitative analyses,   The UV-1900i is a double-beam UV-Vis spectrophotometer using   Measurement Systems  Environmental
          photometrics, DNA/protein quantitation, and high-level multi-  Shimadzu's original Lo-Ray-Ligh diffraction grating technology. Low
          component quantitation can also be performed. This means that it is   stray light levels and high reproducibility (photometric repeatability)
          fully equipped with all of the measurement functions required of a   ensure quantitative analysis can be performed accurately for either low   Systems  Non-Destructive Inspection     Material Testing and
          UV-VIS spectrophotometer, thus making it an "All-in-One UV"   or high concentrations. In addition to high performance, it also offers
          instrument. By configuring the D 2 /WI lamp with a monitor double beam   ultra-fast scanning for acquiring highly accurate spectra in just a few
          system, more than sufficient stability can be obtained despite its small   seconds. It also supports network connectivity. It is possible to check the
          size. Equipped as standard with instrument validation, which facilitates   acquired data even from a room with no equipment installed.
          maintenance inspections for the instrument.         (Additional expansion memory required). In addition to stand-alone
          Wavelength range  190 to 1,100 nm                   operation using a color touch panel, PC control using LabSolutions
          Spectral bandwidth  5 nm                            UV-Vis software is also possible.
          Stray light  0.05 % max.                             Measurement wavelength range  190 to 1,100 nm          Measurement Systems  Physical Properties
                     Photometric, spectrum, quantitation, kinetics, time scan,   Spectral bandwidth  1 nm
          Installed software  multi-component quantitation, DNA/protein quantitation,
                     instrument validation                     Wavelength scanning speed  29,000 nm/min maximum speed
                                             Brochure No. C101-E130  Stray light  Less than 0.02% (220 nm, Nal and 340 nm, NaNO 2)
                                                                                                  Brochure No. C101-E168
