Cell Culture Media Analysis Platform /
    Nucleic Acids and Proteins Analyzers



            Cell Culture Media Analysis Platform                 Web Application Supporting Cell Observation
            C2MAP System                                         Cell Pocket Ver. 2                          New



                                                                               Cell Type: iPS
                                                                               Medium: AAA
                                                                               Scaffold: Lamin 511
                                                                               …


                                                                                      Cell Pocket
                                                                                       SERVER
                                                                                                       Cell Type: iPS
                                                                                                       Medium: AAA
                                                                                                       Scaffold: Lamin 511
                                                                                                       …


            The C2MAP system measures component changes in a culture supernatant as   Cell Pocket is a web application that makes cell image analysis and
            culturing progresses using LC/MS/MS. It can be used in a wide range of   management incredibly easy. The web application is paired with deep
            applications, from basic research of cell cultures including pluripotent stem cells   learning to offer quick and easy gathering, analysis, and sharing of lab
            (iPS cells and ES cells), mesenchymal stem cells, and antibody-producing cells, to   member data whether from the office or the laboratory.
            scaling up culture volumes, and actual process development.  Quantify the visual state of cells from various aspects
            Automated Process from Pretreatment for the Culture Supernatant Analysis to Measurement  • Deep learning technology can offer the quantification of cell status.
                                                                 • Easy quantifying and graphing with customizable analysis recipes.
            Seamless analysis and management can be performed for from the pretreatment
    Life Science Lab Systems
                                                                 Centralized management of all data from cell observation work
            unit to the LC/MS/MS measurement.                    •  Easy to gather various cell culture information such as culture conditions, image
            Supports a Wide Range of Measurement Compounds and Culture Supernatant Samples  data, and analyzed data.
            A total of 95 components can be simultaneously analyzed at high speed, including   • Can be used by up to 20 users.
            major basal culture media components for animal cells, and secreted metabolites.  •  Centralized management facilitates sharing data and knowledge among members.
            Easy Confirmation of Component Variations in Culture Media  User interface specialized for cell culture management
            Temporal changes in the components obtained can be displayed as trend graphs.  • Cell image data can be easily linked to culture conditions.
                                                                 •  The user interface for culture management is simple and easy to understand and
            The results under multiple experimental conditions can be overlaid in the display,
                                                                  supports a user’s cell analysis work.
            enabling comparative analysis.                                                           Brochure No. C297-E139
                                                Brochure No. C297-E120
            Automated Picking and Collecting Tool of Cell Colonies  MCE-202 Microchip Electrophoresis System for DNA/RNA Analysis
            CELL PICKER                                          MultiNA


















            The CELL PICKER system automates the pickup and removal of cell   This system is used to analyze the size of DNA/RNA samples, with
            colonies using a pipetter. Easy-to-operate software simplifies the cell   convenient analytical operability. It achieves analysis costs on par with
            pickup process. Cell pickup can be made even easier by connecting   agarose gel electrophoresis, and can perform fully automatic analyses of
            AUTO CHANGER, new optional equipment designed with automation   up to 108 samples. Using optimized reagent kits (four types for DNA
            in mind.                                             analysis and one type for RNA analysis), the system achieves a high
            Stress-Free Operations                               resolution and high sensitivity. It can significantly improve the workflow
            Unstable and delicate procedures during cell pickup are automated, so   for mutation checks in genome editing, and genotype determination.
            the operator can focus on the cell selection process. The software is   Detection method  Fluorescence detection using a fluorescence intercalator
            simple to operate.                                   Maximum number of samples 108
            Ensuring Traceability                                               25 to 500 bp (DNA-500 kit)
                                                                                100 to 1,000 bp (DNA-1000 kit)
            Procedural control and standardization are ensured by methods   Size range  100 to 2,500 bp (DNA-2500 kit)
            (procedural conditions). In addition, images of the cells can be recorded   100 to 12,000 bp (DNA-12000 kit)
            automatically before and after pickup.                              28S rRNA (5.0 knt) or below (RNA kit)
                                                                                Analysis results obtained and displayed in as short as
                                                Brochure No. C297-E127  Analysis processing speed  approx. 80 seconds
                                                                                                     Brochure No. C297-E062
