Gas Chromatograph Mass Spectrometers



          Thermal Desorption System                           GC-MS Application System
          TD-30 Series                                        Off-Flavor Analyzer                                      Chromatography Systems














                                           GCMS-TQ8040 + TD-30R                                                        Mass Spectrometry Systems



          Thermal desorption systems heat samples in a sample tube and then   This analysis system can reliably identify the substances responsible for
          concentrate the thermally desorbed gases before injection into a GC or   off-flavor problems. To resolve off-flavor issues, the substances causing
          GC-MS system. They are commonly used to measure volatile organic   the odor must be identified. In order to accurately identify them
          compounds (VOCs) in the atmosphere or measure trace components   however, expertise and experience are required to know what   Life Science Lab Systems
          that are generated from plastic or other samples. It is now possible to   components are responsible for the off-flavor problems, to discriminate
          target a wide variety of components, from low boiling point to high   the quality of their odors and to use odor thresholds for those
          boiling point. The lineup includes the TD-30, which can hold a maximum   discriminations. The system provides a database of the major odor-
          of 60 samples, and the TD-30R, which can hold 120 samples and   causing substances, as well as sensory information (odor qualities and
          supports re-acquisition and the addition of internal standard substances.   odor thresholds), for use in combination with GC-MS. It provides the
          System configuration example  GCMS-TQ8040 NX + GCMSsolution + TD-30/30R  total solution needed for off-flavor analysis.
          Number of samples  TD-30: 60, TD-30R: 120                           GCMS-QP series, GCMS-TQ series
          Tube desorption temperature  Room temperature +15°C to 430°C (Accuracy ± 1°C)  Multifunctional autosampler: AOC-6000 Plus or AOC-5000   Spectroscopy Systems
          Trap method    Cold trap (cooled with Peltier element)  System configuration example Plus
          •  A system can be constructed with the GCMS-TQ series and GCMS-QP series. Contact your   Sniffing port: PHASER (GL Science B.V.)
                                                                              Multimode inlet: OPTIC-4 (GL Science B.V.)
          Shimadzu representative for further details.
                                             Brochure No. C146-E349                               Brochure No. C146-E292
          GC-MS Application System                            GC-MS Application System
          AOC-6000 Plus Multifunctional Autosampler System    OPTIC-4 Multifunction Sample Injection System           Systems  X-ray and Surface   Analysis



















          The AOC-6000 Plus supports multiple sample injection methods   The OPTIC-4 is a GC injection inlet that supports all GC-MS sample   Measurement Systems  Environmental
          including liquid sample injection, headspace (HS) injection and solid   injection modes, including large-volume injection, injection port
          phase micro extraction (SPME). Consequently, it can be used for   derivatization, thermal desorption, and difficult matrix introduction
          analyzing samples in wide range of formats. Furthermore, it can   (DMI). It can be combined with the AOC-6000 for automatic insert   Systems  Non-Destructive Inspection     Material Testing and
          automatically switch between sample injection methods, so that a   replacement to further enhance productivity for multi-sample analysis.
          combination of different sample injection methods can be used within a   System configuration example  GCMS-TQ8040 NX + GCMSsolution + OPTIC-4
          single sequence of operations. New functions for managing syringe and   Split/Splitless, large-volume, injection port derivatization,
          fiber usage history support accurate analysis.       Injection modes  thermal desorption, thermal extraction, and difficult matrix
                                                                              introduction (DMI) injection modes
          System configuration example  GCMS-TQ8040 NX + GCMSsolution + AOC-6000 Plus  Max. operating temperature  600°C (35°C GC oven temperature)
                         162 2 mL vials (54 × 3) per tray      Heating rate   1 to 60°C/sec
          Sample capacity  45 10/20 mL vials (54 × 3) per tray  Pressure range  7 to 700 kPa
                         (Up to 2 trays can be loaded)
          Syringe heating temperature  35 to 150 °C (1 °C steps)  Total flow range  5 to 500 mL/min (helium)          Measurement Systems  Physical Properties
                                             Brochure No. C146-E396                               Brochure No. C146-E185
