Liquid Chromatograph Mass Spectrometers
Optional Software for LabSolutions Insight Open Access Software for LC and LCMS
LabSolutions Insight Explore Open Solution
Mass Spectrometry Systems
This software supports everything from qualitative analysis to Supports LC and LCMS analysis in an open access environment. After
quantitative analysis of accurate mass spectrometry data. In addition to logging in on the sample registration window, registration of samples
quantitative data processing for multiple analytes, it also enables highly and the analyses can be performed in one window. Moreover, data can
precise library searches, structural analysis, formula prediction, and be displayed using the Open Solution data browser simply by clicking
multiply-charged ion analysis based on high-resolution and high- the link in the e-mail that is sent after the analysis is complete. Once the
accuracy mass spectrometer data. It includes a variety of functionality, data browser has been set up on the server PC, all members of a
such as “Analyze” functionality for predicting the composition of research team can view the data without installing software on their PC.
unknown compounds or searching for the molecular or structural In the data browser, peaks can be added or deleted for the
formula based on accurate mass data, or “Assign” functionality for chromatogram using simple operations. Also, since structural formulas
predicting the fragmentation patterns of molecular structures or and the like can be easily pasted into the window when creating
calculating the attribution of respective fragments to specific spectral reports, the degree of perfection for such reports is enhanced. When a
peaks. All of the extensive functionality works together seamlessly to multiple number of mobile phases and columns are being used, the
minimize the effort involved in analyzing data from accurate mass cleaning of the flow path is executed automatically, so the system can
spectrometry. be operated with great stability.
Note: LCMS-9030/9050, LCMS-2010 series, LCMS-QP8000 series, and LCMS-IT-TOF systems are not supported.
For LCMS-8060/8050/8045/8040/8030 LC/MS, GC/MS Data Analysis Software
LC/MS/MS Method Packages Multi-omics Analysis Package New
The MRM conditions must be optimized before performing quantitation
by MRM. However, this imposes a greater burden on the operator as
the number of compounds subjected to simultaneous analysis increases.
The Multi-omics Analysis Package is metabolic engineering software
Residual Pesticides 836 components
Veterinary Drugs 129 compounds that can automatically generate metabolic maps and perform a variety
Water Quality Analysis 76 compounds of data analysis based on the vast amounts of mass spectrometry data
Rapid Toxicology Screening 231 compounds generated in fields such as metabolomics, proteomics, and flux analysis.
Primary Metabolites 198 compounds In conjunction with the various method packages and databases offered
Lipid Mediators 214 compounds by Shimadzu for metabolomic analysis, the Multi-omics Analysis
Cell Culture Profilling 144 components
D/L Amino Acids 22 amino acids Package can help increase the efficiency of metabolomic data analysis
Mycotoxins 27 mycotoxins work. It makes it easy to use volcano plots for comparing two groups,
Short Chain Fatty Acids 22 components principal component analysis (PCA) for comparing multiple groups,
Forensic Toxicology Database more than 2,500 compounds hierarchical clustering analysis (HCA), and box plots. Linked PCA, HCA,
Aminoglycoside Antibiotics 13 aminoglycosides
Restricted Chemicals in Textiles 105 compounds and box plot results can be displayed in the same window to
Bile Acids 49 bile acids conveniently identify significant compounds. The metabolic map can be
Modified Nucleosides 4 components enlarged to confirm where identified compounds are located on the
PFAS in Drinking Water 52 compounds map and to support confirming and interpreting the data. The intuitive
Glycosaminoglycans 6 glycosaminoglycans visualization of data provides powerful support for drug discovery,
Reactive Sulfur Profiling 17 sulfur-containing metabolites
Brochure No. C10G-E094 functionally enhanced foods, bioengineering, and other life science
22 research applications.
Brochure No. C146-E385
