FTIR Spectrophotometers
             New    Fourier Transform Infrared Spectrophotometer

            IRXross



            IR, Xross over


            Performance × Operability

            The IRXross creates a new concept for infrared spectroscopy. It offers
            the optimal solution for a new era with diverse application
            requirements.
                                                                                                            Movies >
             High-End Sensitivity for Countless Applications      Built-in Analytical Intelligence
            55,000:1 S/N Enables Ultra-High-Sensitivity Measurements  Easy Navigation with IR Pilot
            The IRXross is a mid-level FTIR model that achieves high-end level S/N. It   Ensures Anyone Can Get
            enables best-in-class low noise with P–P values of 55,000:1 for one minute   Started Easily
            of integration. Using the IRXross with a single-reflection ATR attachment,   A total of 23 macro application
            an oil stain on paper was analyzed. The system can detect even the   programs are included. Even
            extremely weak 0.00023 absorbance signal with good sensitivity.  operators unfamiliar with FTIR
               Abs                                               analysis can analyze samples
              0.0004                  2,920.23 cm −1
                                                                 easily by simply selecting the
                                            2,850.79 cm −1
              0.0003                                             purpose of analysis and
                                                                 attachment used. There is no
              0.0002
                                                  0.00023        need to set parameters. Multiple
              0.0001                                  Abs        samples can be analyzed with a single click.
              0.0000
                                                                  Shimadzu’s Proprietary Database Useful for
                3200     3100    3000     2900    2800    2700
                                                          cm −1   Contaminant Analysis
    Spectroscopy Systems
            0.25 cm  Resolution and 20 Spectra/Second Measurement   Contaminant Analysis Program
                   −1
            Enables High-Resolution and High-Speed Measurements  This program is included as a standard
            N 2O gas (500 ppm), considered an environmental problem as a   feature in LabSolutions IR software. The contaminant analysis program
            greenhouse gas, was analyzed. Measuring the gas at high resolution   identifies measured contaminants with high precision using a spectral
            shows the peaks properly separated. In addition, high-speed   library for substances commonly detected as contaminants in
            measurements can accurately analyze the process of completing a   combination with Shimadzu’s proprietary identification algorithm.
            reaction in 0.5 seconds.
               Abs                                 Resolution     Optional Libraries
                                                      0.25 cm −1  Contaminant Library for LabSolutions IR
                                                      0.5 cm −1
                                                      1.0 cm −1  This unique library was created by Shimadzu especially for analyzing
                                                                 contaminants in tap water and food products. The library includes
                                                                 information about samples actually collected as contaminants and
                                                                 service parts commercially marketed for tap water applications. It also
                                                                 includes a collection of X-ray fluorescence profiles (PDF files).
                  2265  2255  2245  2235  2225  2215  2205  2195  2185  2175
                                                         cm −1   Consequently, it can significantly improve the precision of contaminant
                                                                 searches. Unlike previous libraries, this is a mixture library that covers
             Complies Fully with Regulations
                                                                 the extensive knowledge and experience necessary for qualitative
            Humidity-Resistant Window Material Compatible with the   analysis.
            Wavenumber Measurement Range Specified in            Thermal-Damaged Plastics Library
            Pharmacopoeia                                        Unlike previous libraries, this library includes information about plastics
            Either a KBr or KRS-5 window can be selected. The KRS-5 window   that have degraded due to oxidation by heating. The library is especially
            maintains humidity resistance up to 90 %RH (for temperatures up to 30   useful for analyzing degraded contaminant substances, which are
            °C) and is compliant with pharmacopoeia wavenumber range   common.
            requirements (350 to 7,800 cm ).                     UV-Degraded Plastics Library
                                  −1
                                                                 Unlike previous libraries, this library includes information about plastics
                        KBr                KRS-5
                        Window             Window                degraded by ultraviolet rays. Because many contaminants are degraded,
              Window Material                                    this library is especially useful for such cases. It is also useful for
                                      KBr               KRS-5
                                                                 analyzing microplastics.
                        With humidity-resistant coating  Max. humidity at installation site:
             Humidity Resistance Max. humidity at installation site: 90 %RH (provided no condensation  Interferometer  Michelson interferometer (30° incident angle)
                        70 %RH (with no condensation)   at temperatures up to 30 °C)  Equipped with Advanced Dynamic Alignment system
                                                                 Wavenumber range  7,800 to 350 cm −1
             Wavenumber Range        350 to 7,800 cm −1          Highest resolution  0.25 cm −1
                                                                                                     Brochure No. C103-E135
              Transmittance  About 90 %T        About 70 %T
