Application  No.L476
    News

            n Rapid Analysis of 2,4-DNPH-Derivatized Aldehydes
               and Ketones                                       mV (×10)
            Next, we investigated the use of the Shim-pack XR-ODS                              n  Peaks
            (75 mm × 4.6 mm, 2.2 µm) column to shorten the run                                  1. Formaldehyde

                                                                                                2. Acetaldehyde
            time. Fig. 3 shows the resulting chromatogram, and   5.0                            3. Acetone

            Table 3 shows the analytical conditions used. The              1                    4. Acrolein

                                                                                                5. Propionaldehyde
            detection limit of formaldehyde was determined to be   4.0                             6. Crotonaldehyde
                                                                                                7. 2-Butanone
            12 pg, and the limit of quantitation, 37 pg. Even with                                 8. Methacrolein
                                                                                                9. n-Butyraldehyde
            the analysis time shortened by half, from 30 minutes to   3.0     2   4                10. Benzaldehyde
            15 minutes, the chromatogram showed no adverse                       3  5             11. Valeraldehyde
                                                                                                12. m-Tolualdehyde
            effects on resolution or peak shape.                 2.0                  6  8      13. Hexanaldehyde
                                                                                       7 9
                                                                                           10  11
                                                                 1.0                           12  13
                                                                             2
                                                                                      7      11   13
                         Table 3  Analytical Conditions          0.0
             Column     : Shim-pack XR-ODS (75 mm L. × 4.6 mm I.D., 2.2 µm)
             Mobile Phase   : A : Water/THF = 8/2                 0.0    2.5    5.0   7.5    10.0  12.5   min
                          B : Acetonitrile
             Time Program   : B Conc. 20 % → 60 % (15 min) → 20 % (15-17 min)
             Flowrate   : 1.5 mL/min                                 Fig. 3  Chromatogram of Standard Sample
             Injection Volume : 10 µL                                     (each at 1.0 mg/L as carbonyl compounds)
             Column Temp.   : 40 °C
             Detection   : UV 360 nm
            n Linearity in Rapid Analysis
            Calibration curves were also generated using the Shim-    ×10 5
            pack XR-ODS for high-speed analysis of solutions at    7     Formaldehyde
            concentrations ranging from 0.03 to 3 mg/L (10 µL
            injected) prepared by stepwise dilution of the stock   6     2-Butanone               R =0.99996
                                                                                                   2
            standard solutions of the thirteen 2,4-DNPH-derivatized      Hexanaldehyde
            aldehydes and ketones. Fig. 4 shows the calibration    5
            curves for formaldehyde, 2-butanone, and
            hexanaldehyde. These also showed excellent linearity   4                              R =0.99997
                                                                                                   2
                  2
            with R  values greater than 0.9999. The area %RSD      Peak Area
            values at a concentration of 1.0  mg/L for all         3
            components were within 1 %, as shown in Table 4.
                                                                   2
                                                                                                  R =0.99995
                                                                                                  2
                                                                   1
                     Table 4  Repeatability of Peak Area (n=3)
                          Area %RSD              Area %RSD         0
              Formaldehyde  0.255   Methacrolein   0.229             0         1          2          3
              Acetaldehyde  0.139   n-Butyraldehyde  0.333                      Concentration (mg/L)
              Acetone       0.139   Benzaldehyde   0.247
              Acrolein      0.226   Valeraldehyde  0.101                         Fig. 4  Linearity
              Propionaldehyde  0.171  m-Tolualdehyde  0.917
              Crotonaldehyde  0.423  Hexanaldehyde  0.579
              2-Butanone    0.333

















                                                                                                      First Edition: Nov. 2014


                                               For Research Use Only. Not for use in diagnostic procedures.
                                               The content of this publication shall not be reproduced, altered or sold for any commercial purpose without the written approval of Shimadzu.
                                               The information contained herein is provided to you "as is" without warranty of any kind including without limitation warranties as to its
                                               accuracy or completeness. Shimadzu does not assume any responsibility or liability for any damage, whether direct or indirect, relating to the
                                               use of this publication. This publication is based upon the information available to Shimadzu on or before the date of publication, and subject
                                               to change without notice.
