LAAN-A-LM-E092







            Application                  Liquid Chromatography Mass Spectrometry

            News                         Simultaneous Analysis of Nine Sweeteners Using


                                         Triple Quadrupole LC/MS/MS (LCMS-8040)
            No.C121





            Artificial sweeteners such as saccharin sodium,    n Analysis of a Standard Mixture
            aspartame, sucralose and acesulfame potassium fall   Fig. 1 shows chromatograms measured from a 5 µL
            under the category of specified additives in Japan's   injected sample of a 10 ng/mL standard mixture of nine
            Food Sanitation Act, for which each specified criteria   sweeteners, analyzed with the analytical conditions
            exist  for  their  use  in  terms  of  eligible  foods  and   shown in Table 1. Chromatograms at around the lower
            amounts used.                                      limit of quantitation (LLOQ) are shown in Fig. 2. The
            Cyclamate, an artificial sweetener used in some regions   retention time, calibration curve range, and correlation
            of the world outside Japan, is an unspecified additive   coefficient for each compound are shown in Table 2.
            within Japan, for which inspection is required on   A calibration point accuracy of within 100 ± 20 % and
            specific imported foods.                           a percentage of area repeatability (%RSD) of within
            In light of these situations, there is a demand for   20 % were employed. Good linearity was obtained for
            analyses of various different sweeteners, not only the   all compounds with a correlation coefficient of 0.997 or
            quantitative testing of permitted sweeteners but also   higher.
            the testing of unspecified sweetener additives.
            This article presents a simultaneous analysis of nine
            sweeteners including both specified additives and
            unspecified additives, using the LCMS-8040 high-
            performance liquid chromatograph-triple quadrupole
            mass spectrometer.

              (×10,000)                                      (×100,000)
                 Acesulfame potassium                        2.5                  Dulcin
              2.5
              0.0                                            0.0
                   5.0  5.5  6.0  6.5   7.0  7.5  8.0   8.5 min   5.0  5.5  6.0   6.5  7.0  7.5  8.0   8.5 min
              (×1,000)                                       (×100,000)
              2.0   Saccharin                                2.5                            Neotame
              1.0
              0.0                                            0.0
                   5.0  5.5  6.0  6.5   7.0  7.5  8.0   8.5 min   5.0  5.5  6.0   6.5  7.0  7.5  8.0   8.5 min
              (×10,000)                                      (×100)
              1.0        Cyclamate                                                            Rebaudioside A
              0.5                                            5.0
              0.0                                            0.0
                   5.0  5.5  6.0  6.5   7.0  7.5  8.0   8.5 min   5.0  5.5  6.0   6.5  7.0  7.5  8.0   8.5 min
              (×1,000)                                       (×100)
              5.0            Sucralose                       5.0                               Stevioside
              0.0                                            0.0
                   5.0  5.5  6.0  6.5   7.0  7.5  8.0   8.5 min   5.0  5.5  6.0   6.5  7.0  7.5  8.0   8.5 min
              (×10,000)
              1.0             Aspartame
              0.5
              0.0
                   5.0  5.5  6.0  6.5   7.0  7.5  8.0   8.5 min
                                 Fig. 1  Chromatograms from a 10 ng/mL Standard Mixture of Nine Sweeteners

                                                  Table 1  Analytical Conditions
                     Column          : Unison UK-C18 (150 mm L. × 3.0 mm I.D., 3.0 µm)
                     Mobile Phases   : A 5 mmol/L Ammonium Formate - Water
                                     : B Methanol
                     Gradient        : B Conc. 0 % (0.0 - 2.0 min) → 70 % (4.5 min) → 90 % (8.0 - 12.0 min) → 0 % (12.01-15.0 min)
                     Flowrate        : 0.2 mL/min
                     Column Temperature   : 40 ˚C
                     Injection Volume   : 5 µL
                     Probe Voltage   : + 4.5 kV (ESI-positive mode) / -3.5 kV (ESI-negative mode)
                     DL Temperature   : 300 ˚C
                     Block Heater Temperature : 500 ˚C
                     Nebulizing Gas Flow   : 3 L/min
                     Drying Gas Flow   : 15 L/min
