Application  No.L507
    News


            Q HPLC Analysis of Low Molecular Weight Soluble               Table 1  HPLC Analytical Conditions
              Dietary Fiber                                     System    :  Prominence-i, RID-20A
            The two beverages were prepared according to the    Column    : Shim-pack SPR-Na (250 mm L. × 7.8 mm I.D., 8 μm) × 2
                                                                Guard Column   : Shim-pack SPR-Na (50 mm L. × 7.8 mm I.D., 8 μm)
            procedure shown in Fig. 1, and analyzed by HPLC. The   Mobile Phase   : Water
            results of HPLC analysis are shown in Fig. 2 and 3   Flowrate   : 0.50 mL/min
            alongside the results of HPLC analysis of maltotriose.   Column Temp.   : 80 ˚C
                                                                Injection Volume  : 20 μL
            Analytical conditions are shown in Table 1. The
                                                                Detection  :  RID-20A
            saccharides detected were divided into monosaccharides,
            disaccharides, and trisaccharides or larger on the
            chromatograms, with trisaccharides or larger being   μRIU
            regarded as the dietary fiber fraction. The published    Dietary fiber
                           1)
            analytical method  states to analyze the trisaccharide
            maltotriose under the same conditions as the sample,   75
            then to include all peaks that elute equal to or earlier
            than maltotriose in the dietary fiber fraction. The
                                   1)
            published analytical method  states to use either a ligand   50                Glucose
            exchange column or gel filtration column for HPLC.
            Analysis was performed using a Shim-pack SPR-Na ligand   25
            exchange column. Ligand exchange columns are mainly
                                                                     Drink A
            used in carbohydrate analysis, and are excellent at      Maltotriose
            separating carbohydrates. Ligand exchange columns can   0
            easily separate glucose from other carbohydrates, and   0  5    10   15    20   25   30   35  min
            are therefore suited to analyses using glucose as an
            internal reference standard as shown below.              Fig. 2  Analysis of Low Molecular Weight Soluble
                                                                         Dietary Fiber in Beverage A
            The actual quantification analysis was performed using
            glucose produced by hydrolysis of starch as an internal   μRIU
            reference standard. The amount of glucose in each   200  Dietary fiber
            sample was calculated by a separate pyranose oxidase                           Glucose
            method, and the amount of low molecular weight      150
            soluble dietary fiber was obtained by multiplying the
            peak area ratio of the dietary fiber fraction to the
            glucose peak by the amount of glucose. Depending on   100
            the sample and HPLC column type, glucose may not
            separate from accompanying components. If glucose   50
            does not separate from other components,               Drink B
            quantification can be performed by adding a known      Maltotriose
            concentration of glycerin or another internal reference   0
            standard after the enzyme pretreatment steps, then    0    5    10   15   20   25   30   35   min
            calculating amounts based on the peak area ratio of the
            dietary fiber fraction to the internal reference standard.   Fig. 3  Analysis of Low Molecular Weight Soluble
            Analytical sensitivity will differ when a compound other     Dietary Fiber in Beverage B
            than glucose is used as the internal reference standard,
            and results will need to be corrected accordingly by
            calculating a coefficient relative to analytical sensitivity
            for glucose.
            The amount of dietary fiber is shown by adding the
            amount of low molecular weight soluble dietary fiber
            calculated by HPLC analysis to the result obtained by a
            separate prosky method. This method of calculation
            includes oligosaccharides in the dietary fiber fraction, so
            to show the amount of dietary fiber in the sample minus   1) Food Labeling Standards
            indigestible oligosaccharides, the amount of indigestible   — Appendix: Methods of analysis of nutritional composition
            oligosaccharides must be deleted from the results. Please     (Notification No. 139 from the Deputy Secretary
                                                                          General of the Consumer Affairs Agency, dated
                                    1)
            refer to the analytical method  for further information.      March 30, 2015) [In Japanese]
