C190-E199










            Technical                    Improved Sample Pretreatment Using

            Report                       Of
ine Supercritical Fluid Extraction



                                         Hidetoshi Terada , Takato Uchikata , Takanari Hattori , Keiko Matsumoto , Yoshiyuki Watanabe ,
                                                                                                            1
                                                                 1
                                                                              1
                                                                                            1
                                                    1
                                         Tadayuki Yamaguchi , Yasuhiro Funada 1
                                                       1
            Abstract:
            Separation  analysis  using  HPLC,  SFC  or  GC  requires  a  pretreatment  step  to  efÿciently  extract  a  target  constituent  from  the  sample  in
            various  forms  (e.g.,  solid).  Constituents  are  usually  extracted  from  solid  samples  using  dissolution  or  solid-liquid  extraction  methods.
            Dissolution methods can only be used when the sample is soluble in a given solvent, and they are difÿcult to optimize depending on the
            analytical conditions. Solid-liquid extraction methods (e.g., Soxhlet extraction) are not suited to the pretreatment of multiple samples as
            they  require  considerable  time  for  extraction  and  non-extraction  (e.g.,  cleaning,  preparation)  operations.  However,  extraction  methods
            involving supercritical °uids  can utilize the characteristics of supercritical °uids  (e.g., high solubility, permeability) to achieve the elution of
            a  target  constituent  from  a  solid  sample  with  high  efÿciency  and  also  allow  automation  during  the  extraction  process.  This  article
            describes the utilization of the Nexera UC SFE pretreatment system, which increases the efÿciency of sample pretreatment for analysis.

            Keywords: supercritical  uid extraction, SFE, of ine SFE




            1.  What Is Super   critical Fluid Extraction?       2. The Nexera UC SFE Pretreatment System
            1. What Is Supercritical Fluid Extraction?
            Supercritical fluid refers to the state of any substance at temperature   The Nexera UC SFE pretreatment system (Fig. 1) is a dedicated pre-
            and  pressure  conditions  above  its  critical  point.  Supercritical  fluids   treatment system that performs of°ine SFE. Solid samples are placed
            combine the ability of liquids to dissolve materials with high diffusivity   in  dedicated  extraction  vessels  (Fig.  2)  and  introduced  into  the
            and  low  viscosity  properties  of  gases.  Supercritical  fluid  extraction   system, after which the system automatically performs the extraction.
            (SFE)  with  carbon  dioxide  is  widely  employed  as  a  pretreatment   The extraction vessels are available in volumes of 0.2 mL and 5 mL
            method for analysis owing to its low critical points (critical tempera-  such that they can be selected based on the sample to be analyzed.
            ture: 31.1 °C, critical pressure: 7.38 MPa), which makes it easy to   The system allows accommodation of a maximum of 48 extraction
            handle, along with its incombustibility, inertness, and low cost. Some   vessels, which are mounted into a rack changer (Fig. 3). This setup en-
            advantages of SFE are shown below:                   ables  extraction  pretreatment  of  multiple  samples  via  automated
            • Supercritical °uids have high permeability and diffusion coefÿcients  sample transfer and cycling. The automation of the multi-sample ex-
              and can therefore be used for highly efÿcient extraction.  traction pretreatment using the Nexera UC SFE pretreatment system
                                                                 substantially reduces the time and labor required for the pretreat-
            • Supercritical °uids achieve extraction at mild temperatures at which  ment operations while also preventing human error.
              target constituents are unlikely to oxidize.
            • Carbon dioxide evaporates, which simpliÿes sample treatment after extraction.
            • Solvent costs are low compared with solvent extraction and other methods.
            • The extraction process can be automated.
            While supercritical carbon dioxide is as hydrophobic as hexane and is
            suited  for  the  extraction  of  fat-soluble  compounds,  it  can  also  be
            used for the extraction of compounds with a wide range of polarities   Fig. 2 E xtraction Vessels
            by adding modifier substances such as methanol and ethanol.











                    Fig. 1 T he Nexera UC SFE Pretreatment System                Fig. 3 R ack Changer
