C190-E202









                                         Effective Analysis Management
            Technical                    Achieved by Method Transfer between

            Report                       HPLC and UHPLC




                                         Akihiro Kunisawa , Daiki Fujimura , Yusuke Osaka 1
                                                                 1
                                                     1

            Abstract:

            High  performance  liquid  chromatography  (HPLC)  is  widely  used  for  the  qualitative  and  quantitative  analysis.  In  recent  years,  ultra-high
            performance liquid chromatography (UHPLC) has been developed signiÿcantly. Facilities that have both UHPLC and HPLC systems often
            apply newly established UHPLC method to ordinary HPLC as well as applying existing HPLC method to UHPLC. During such inter-system
            method application, the method must be modiÿed  properly to meet the requirements from another system. This modiÿcation  is called
            “method transfer”. Method transfer requires to modify existing parameters such as °ow rate and/or time pr ogram.
            Here, we describe the relationship between column dimensions including particle size of packing material and analytical conditions, then
            method transfer from HPLC to UHPLC for high speed analysis and that from UHPLC to HPLC for generalization of analytical conditions as
            well as that from Shimadzu’s system to other vendor’s. We also describe the Shimadzu integrated LC system “Nexera-i MT” that supports
            method transfer and ACTO (Analytical Conditions Transfer and Optimization) Function equipped in the latest LabSolutions LC software.
            Keywords: HPLC, UHPLC, method transfer, ACTO, Nexera-i MT




            1. Background
            1.  Backgr   ound
                                                                                                        HPLC
            In pharmaceutical, food and various industrial fields, HPLC is widely
            used for the analysis of target compounds and related impurities. In
            recent years, UHPLC system that has more than 100 MPa of pressure
            tolerance affords more efficient analysis at ultra-high speed. Due to
            these features, UHPLC systems have been introduced in a variety of
            facilities where R&D departments often use UHPLC systems to devel-
            op an efficient analytical method then modify it to match HPLC analy-
            sis. The method transferred are then used by the QC department.
            Conversely,  an  existing  HPLC  method  can  be  transferred  into  a
            UHPLC method to improve the speed and efficiency of analyses. In
            this report, we define method transfer as both directions of method   0.0  10.0  20.0  30.0  40.0  min
            modifications from HPLC to UHPLC and from UHPLC to HPLC.
                                                                                              Method transfer
            We  often  face  inadequate  separation  in  gradient  elution  after  a        (speed improvement)
            method transfer from HPLC where the separation is completed, to
            UHPLC (Fig.1). Furthermore, even though a method may have been
            created successfully using UHPLC analysis, the method transfer from                       UHPLC
            UHPLC to HPLC gives different selectivity of separation, resulting in a
            degradation of efficiency for the entire laboratory.
            Generally,  a  method  transfer  accompanied  by  employing  different
            column dimensions including particle size must be required to modify
            analytical conditions such as flow rate and time program. However,
            to optimize conditions is not easy and method transfer can result in
            poor  separation  compared  to  those  obtained  prior  to  the  method
            transfer.  Keeping  a  consistent  separation  pattern  before  and  after
            method transfer in terms of parameters, such as resolution and rela-
            tive retention times, requires complex calculations based on pre- and
            post-transfer data, which include column dimensions (length, internal   0.0  1.0  2.0  3.0  4.0  5.0  6.0  min
            diameter, and particle size).
                                                                       Fig. 1  Problems That Arise During Method Transfer
                                                                            (Analysis of cephem antibiotics)

            1 Analytical & Measuring Instruments Division                                                            1
