SCA-130-513



            ■ Calibration                                       ■ Example of a real solid sample (Bauxit)
            The SSM calibration  can be carried out at          TC determination
            different manner. A solid (with known C-            Result: 1.30 ± 0.001% (CV: 0,11%)
            content) is  weight in a ceramic boat or a
            standard solution is added to a sample boat
            filled with ceramic wool.

            In  case  of  solid  calibration,  different  weights
            in of one compound (for example glucose)
            are used. Based on the carbon content of the
            compound (Glucose contains 40%  carbon)
            the  absolute  carbon  content  in  the  boat  is
            calculated (in µg) and used for the calibration
            graph (x-axis).

                                Kal. Kurve
                2136,2
                                                                IC determination
                                                                Result: 0,94 ± 0.009% (CV: 0,95%)
                1500
              Fläche  1000


                500

                0
                   0      4000    8000   12000       18101,6
                                   Abs C [ug]

                    Figure: TC-Calibration with Glucose

            The  IC  calibration  can  be  done  with  sodium
            hydrogen carbonate (for instant).


                                Kal. Kurve
                1234,2
                                                                TOC-Result: 0,36%

                900
                                                                ■Recommended analyzer / Configuration
              Fläche  600                                       TOC-L  or TOC-V wet chemical
                                                                SSM-5000A
                300

                                                                Example of Application
                0
                   0     2000   4000  6000   8000    10644,5    108    TOC determination in solids
                                   Abs C [ug]
                                                                203    TOC determination in cleaning
                     Figure: IC-Calibration with NaHCO 3
                                                                       validation – SWAB method
