Page 26 - Pharmaceutical Solution for Pharma Analysis
P. 26

LC-15-ADI-036


              (x100,000,000)                                   150 Inten.
             1.0
                                                               140
             0.9                                               130
             0.8                                               120
                                                               110                          422.15
             0.7
                                                               100                             448.15
             0.6                                                90
                                                                80
             0.5
                                                                70
             0.4                                                60
             0.3                                                50
                                                                40
             0.2                                                30
             0.1                                                20     250.15  276.15  292.10  318.10  362.15  370.05  380.10  406.05  430.20  541.20
                                                                10           302.00
             0.0
                                                                0
                  1.0  2.0  3.0  4.0  5.0  6.0  7.0  8.0  9.0  min  225.0  250.0  275.0  300.0  325.0  350.0  375.0  400.0  425.0  450.0  475.0  500.0  525.0  m/z
                    Figure 11. TIC of Product ion scan, imp H           Figure 12. MS/MS spectrum of imp H
              (x10,000,000)
                                                                Inten.
                                                               140
             3.5
                                                               130
             3.0                                               120
                                                               110                            454.15
             2.5                                               100
                                                                90
             2.0                                                80
                                                                70
             1.5                                                60
                                                                50
             1.0
                                                                40
                                                                30
             0.5                                                             292.10
                                                                20      250.10          394.20  436.15  480.15
                                                                10         276.15  294.10  318.20  376.15  418.20  573.20
             0.0
                                                                0  200  250  300  350   400  450  500   550  m/z
                  1.0  2.0  3.0  4.0  5.0  6.0  7.0  8.0  9.0  min
                 Figure 13. TIC of Product ion scan, unknown imp  Figure 14. MS/MS spectrum of unknown imp
             >>Existing method
                                                                   8-12 hours
                            30 min
              Synthesis    Fractionation                Powderization (centrifugal dryer or freeze dryer etc)  Approx.  8-12.5 hours
                      Mobile phase derived                     Takes time due to high water content
                      components remain
             >>Prominence UFPLC                 30 min    20 min   10 - 40  min
                                                                                Takes only
                                                         Concentrate
                                     Synthesis  Fractionation  and               Powderization  one and half
                                                           Purify               hours
                                                           Mobile       Short
                                                         phase derived    because no
                                                         components   water is
                                                          removed    contained
                                               Figure 15. UFPLC purification cycle
               With the dedicated Purification Solution software, the analysis status can be quickly confirmed at a glance
               using the peak tracking function.
