SPM Data Room Website

The SPM Data Room website includes examples of new observation data, applications, a list of
scientific articles, and a list of presentations.

Applications Observation Examples TOP Scienti c Article List Presentation List

https://www.shimadzu.com/an/surface/spm/dataroom.html

SPM Data Room

01 Living Organisms 03 Non-Metals

E. coli Bacteria Ferroelectric Domains
E. coli bacteria were dried on a
substrate and observed in liquid
media.
(Data provided by Ms. Ikemoto and
Dr. Kogure, Atmosphere and Ocean
Research Institute, The University of Etched Surface of
Tokyo) Pb(Zn1/3 Nb2/3)O3-20%
PbTiO3 Single Crystal
Plates

By etching the surface, the domain wall structure of ferroelectric crystal
surfaces can be observed.
(Data provided by Dr. Iwata, Faculty of Engineering, Nagoya Institute of
02 Metals Technology)
Boundary Surface of Plating Layer
A cross-section of a copper
(Cu) plated iron (Fe) sample
was prepared, and the
electric potential measured
along the boundary surface.
The topographic image on
the left does not show any
Topography image Potential image change in thickness, but the
electric potential image on
the right shows that the
iron portion has a potential
that is about 90 mV higher.
