Page 57 - Shimadu Consumables Catalog

Cartridge Guard Columns
Particle Size I.D. (mm) Cartridge Guard Column (2pcs) Holder
(μm) Length (mm) 1.0 1.5 3.0 4.0
10 227-30226-01 227-30227-01 227-30228-01 227-30230-01 227-30532-01
3
20 - - 227-30229-01 227-30231-01 227-30532-02
10 227-30232-01 227-30233-01 227-30234-01 227-30236-01 227-30532-01
5
20 - - 227-30235-01 227-30237-01 227-30532-02
Particle Size I.D. (mm) Cartridge Guard Column (2pcs) and Holder
(μm) Length (mm) 1.0 1.5 3.0 4.0
10 227-30226-02 227-30227-02 227-30228-02 227-30230-02
3
20 - - 227-30229-02 227-30231-02
10 227-30232-02 227-30233-02 227-30234-02 227-30236-02
5
20 - - 227-30235-02 227-30237-02
Analytical Columns (High-Pressure Series)

Particle Size I.D. (mm) Pressure Tolerance
(μm) Length (mm) 2.1 3.0 4.6 (MPa)
30 227-30207-01 227-30208-01 -
50
50 227-30207-02 227-30208-02 -
2 75 227-30207-03 227-30208-03 -
100 227-30207-04 227-30208-04 -
80
150 227-30207-05 227-30208-05 -
30 227-30243-01 227-30244-01 227-30245-01
50 227-30243-02 227-30244-02 227-30245-02
75 227-30243-03 227-30244-03 227-30245-03
3 50
100 227-30243-04 227-30244-04 227-30245-04
150 227-30243-05 227-30244-05 227-30245-05
250 227-30243-06 227-30244-06 227-30245-06

Cartridge Guard Columns (High-Pressure Series)

Particle Size I.D. (mm) Cartridge Guard Column (2pcs) Pressure Tolerance Holder
(μm) Length (mm) 1.5 2.1 3.0 (MPa)
2 10 227-30246-01 227-30247-01 227-30248-01
80 227-30533-01
3 10 227-30249-01 227-30250-01 227-30251-01
Particle Size I.D. (mm) Cartridge Guard Column (2pcs) and Holder Pressure Tolerance
(μm) Length (mm) 1.5 2.1 3.0 (MPa)
2 10 227-30246-02 227-30247-02 227-30248-02
80
3 10 227-30249-02 227-30250-02 227-30251-02

Pre-column Type Guard Columns (High-Pressure Series)

Particle Size I.D. (mm) 2.1 3.0 4.6 Pressure Tolerance
(μm) Length (mm) (MPa)
2 227-30795-01 227-30796-01 227-30797-01 80
30
3 227-30798-01 227-30799-01 227-30800-01 50
