Cartridge Guard Columns
Particle Size I.D. (mm) Cartridge Guard Column (2pcs) Holder
(μm) Length (mm) 1.0 1.5 3.0 4.0
10 227-30179-01 227-30180-01 227-30181-01 227-30183-01 227-30532-01
3
20 - - 227-30182-01 227-30184-01 227-30532-02
10 227-30185-01 227-30187-01 227-30188-01 227-30190-01 227-30532-01
5
20 - - 227-30189-01 227-30191-01 227-30532-02
Particle Size I.D. (mm) Cartridge Guard Column (2pcs) and Holder
(μm) Length (mm) 1.0 1.5 3.0 4.0
10 227-30179-02 227-30180-02 227-30181-02 227-30183-02
3
20 - - 227-30182-02 227-30184-02
10 227-30186-02 227-30187-02 227-30188-02 227-30190-02
5
20 - - 227-30189-02 227-30192-02
Analytical Columns (High-Pressure Series)

Particle Size I.D. (mm) 2.1 3.0 4.6 Pressure Tolerance
(μm) Length (mm) (MPa)
30 227-30160-01 227-30161-01 -
50
50 227-30160-02 227-30161-02 -
2 75 227-30160-03 227-30161-03 -
100 227-30160-04 227-30161-04 -
80
150 227-30160-05 227-30161-05 -
30 227-30198-01 227-30199-01 227-30200-01
50 227-30198-02 227-30199-02 227-30200-02
75 227-30198-03 227-30199-03 227-30200-03
3 50
100 227-30198-04 227-30199-04 227-30200-04
150 227-30198-05 227-30199-05 227-30200-05
250 227-30198-06 227-30199-06 227-30200-06

Cartridge Guard Columns (High-Pressure Series)

Particle Size I.D. (mm) Cartridge Guard Column (2pcs) Pressure Tolerance Holder
(μm) Length (mm) 1.5 2.1 3.0 (MPa)
2 10 227-30201-01 227-30202-01 227-30203-01
80 227-30533-01
3 10 227-30204-01 227-30205-01 227-30206-01
Particle Size I.D. (mm) Cartridge Guard Column (2pcs) and Holder Pressure Tolerance
(μm) Length (mm) 1.5 2.1 3.0 (MPa)
2 10 227-30201-02 227-30202-02 227-30203-02
80
3 10 227-30204-02 227-30205-02 227-30206-02

Pre-column Type Guard Columns (High-Pressure Series)

Particle Size I.D. (mm) 2.1 3.0 4.6 Pressure Tolerance
(μm) Length (mm) (MPa)
2 227-30789-01 227-30790-01 227-30791-01 80
30
3 227-30792-01 227-30793-01 227-30794-01 50
