Application   No. C154
    News


            „  Experimental
            Pesticide spiked samples, extracted using established
                                                               Table 2  MS/MS methods used to acquire data in MRM Spectrum
            QuEChERS based methods, were provided by Scientific   Mode and a conventional MRM method with 2 MRM transitions
            Analysis Laboratories, UK. In order to test the     per compound. As part of the comparative study, the same LC
            performance of the MRM Spectrum Mode database               conditions were used for both methods.
            and library searching a number of matrices were tested   LC-MS/MS Mass   MRM Spectrum   2 MRM method
            including turmeric, plum, peppermint, parsnip, cherry,   spectrometry   Mode: generating
            lime, pumpkin, tomato and potato. Final extracts were               library searchable
            prepared in  acetonitrile without any dilution and                  spectra
            directly injected into the  LC-MS/MS. A water co-   Target number of   193        193
            injection method, performed automatically in the auto-  compounds
            sampler, was used to improve early  eluting peak    Total number of MRM  1,291 transitions   386 (374 in ESI+ and
            shapes in addition to a sub 2 micron  particle size   transitions   (1,229 in ESI+ and 62   12 in ESI-)
            column to improve peak capacity (Table 1) .                         in ESI-)

                                                                Pause time/dwell   1 msec./3 msec.   1 msec./3 msec.
            Calibration curves were prepared in the range 0.01 to   time
            0.2 mg/kg. Repeatability of the method was tested   Ionisation mode  ESI +/-      ESI +/-
            using avocado matrix at 0.1 mg/kg. In the final method
            samples were analysed in  ESI +/- using a polarity   Polarity switching   5 msec  5 msec
            switching time of 5 msec.                           time
                                                                Interface       350 °C        350 °C

            On average 7 MRM transitions were applied to each   temperature
            compound, with more than 10 MRM transitions applied
                                                                Heat bl°Ck      300 °C        300 °C
            to 34 compounds. All MRM transitions were acquired   temperature
            throughout the MRM window  without the need  for
                                                                Desolvation line   150 °C     150 °C
            triggering thresholds. The method includes a total of   temperature
            1,291 MRM transitions for 193 pesticides in a run time
            of only 15 minutes. A dwell time of 3 msecs was applied   Nebulising gas  3 L/min  3 L/min
            to every MRM transition. In order to evaluate the data   Heating gas  10 L/min    10 L/min
            quality from the MRM Spectrum Mode method, the
            same method was set up with 2 MRMs applied to each   Drying gas     10 L/min      10 L/min
            compound (386 MRMs in total) using the same
            acquisition method (Table 2).
                                                               „  Results and Discussion

            LabSolutions  software was used to automatically   In developing monitoring programs for chemical
            optimize the fragmentation for all pesticides and   contamination methods are designed to determine a
            generate a MRM Spectrum mode method. The MRM       list of known analytes with a focus on delivering a rapid,
            Spectrum Mode method for library searching and     cost-effective analysis that generates no false-negative
            compound verification could be simply and quickly set   or false-positive results. Guidelines for compound
            up using the Shimadzu pesticide database. This     identification have been  published by the EU in
            database contains more than 6,000 MRM transitions for   directive SANTE/11945/2015 . This identification
            over 750 pesticides.                               criteria requires at least two MRM transitions with an
                                                               ion ratio and retention time within defined tolerance

            LabSolutions Insight v3.0 software was used to review   limits.
            quantitative data and MRM Spectrum mode library
            searching with advanced filtering tools to review by   To help reduce false detect reporting in pesticide
            exception and to reduce false detect reporting.     monitoring programs, a MRM method was developed
                                                               with a higher number  of  MRM transitions for  each

                       Table 1  LC acquisition parameters      target pesticide to increase the level of confidence in
                                                               assay specificity.  By combining multiple MRM
             Liquid chromatography
                                                               transitions for a compound into a product ion
             UHPLC            Nexera LC system                 spectrum, pesticide identification can be verified and
                                                               confirmed against a MS/MS reference spectral library.
             Analytical column     HSS T3 (100 × 2.1, 1.7 μm)
                                                               Using MRM Spectrum mode can help markedly reduce
             Column temperature   40 °C                        false detect reporting without affecting the data
                                                               quality for optimized quantitation or identification.
             Flow rate        0.4 mL/minute

             Solvent A        5 mmol/L ammonium formate and    Fig. 2, shows the MRM  chromatogram for all 193
                              0.004 % formic acid
                                                               pesticides spiked at 0.010 mg/kg measured with MRM
             Solvent B        5 mmol/L ammonium formate and    Spectrum mode. Using this mode 1,291 MRM
                              0.004 % formic acid in methanol   transitions were measured for 193 pesticides. Despite
             Binary Gradient   Time (mins)  %B                 the high data density acquired with MRM Spectrum
                                                               Mode (for example, 151 MRM transitions were
                              1.50          35
                                                               registered in the same time window during the analysis,
                              11.50         100                see Fig. 3) sensitivity was not affected by the high data
                                                               acquisition rate.
                              13.00         100
                              13.01         3
                              15.00         Stop
             Injection volume   0.1 μL (plus 30 μL water)
