Application                    Food and Beverages / GC-2010

            News

                                           A Comparison Study of Different Capillary
                                           Columns for Analysis of Alcohol Congeners
                   AD-0124Ph               in Alcoholic Beverages


             Introduction

            Alcoholic beverages contain a wide range of volatile components, primary of which are alcohols and short-chain aldehydes.
            To ensure consistency in the quality and flavour of the finished products, distilleries and alcoholic beverage manufacturers
            monitor the presence and relative levels of these compounds. Gas chromatography (GC) is usually the preferred technique
            in analysing these compounds. Fifteen components as listed in Table 1 are monitored by ethanol distilleries and alcoholic
            beverage manufacturers in the Philippines. The Association of Official Analytical Chemists (AOAC) and the Commission of
            the European communities have published methods for the analysis of fusel oils, methanol, ethanol, aldehydes and higher
            alcohols by GC in spirit drinks and distilled liquors [1~3]. The conventional GC methods for alcoholic beverage analysis are
            based on packed column, because glass tubing material for the packed column is inert, rarely causes tailing or
            decomposition of samples and minimizes interaction between the target component and the walls of the tube. However,
            packed glass columns are prone to breakage and may cause adsorption of the more reactive components present in
            alcoholic beverages. Most modern GC instruments are configured for capillary column use for the inherent advantages over
            packed columns such as more efficient separation, narrower peaks and consequently, lower limits of detection. This
            motivates an investigation into the potential of using capillary column in separating alcohols, aldehydes and other congeners
            typically found in alcoholic beverages. In this study, four capillary columns are selected and their performance are compared
            with packed column in terms of separation of all key components found in alcoholic beverages.

             Experimental                                      Table 1: Alcohols, aldehydes and other compounds
                                                                monitored in local alcoholic beverages
            Methods and Standard Preparation
                                                                   Peak ID              Component
            Standard solutions containing varying amounts of alcohol  1                 Acetaldehyde
            congeners were prepared in accordance with in-house       2                   Acetone
            procedures. All solutions were diluted to volume with 40%
            (v/v) ethanol in water. The linear velocity of He carrier gas  3            Ethyl acetate
            of GC for each column was optimized to achieve the best   4                    Acetal
            separation. The injection and FID detection conditions    5                   Methanol
            were   set  according  to  the  column  supplier’s        6                  Isopropanol
            recommendation or in-house procedures. Four columns       7                N-propyl acetate
            from different suppliers were employed and compared in    8                  N-propanol
                                                                      9
            this work. The columns were chosen based on availability  10               N-butyl acetate
                                                                                         Isobutanol
            and suitability of each column for alcohol congeners     11                Isoamyl acetate
            separation as published in literature [4,5].
                                                                     12                   N-butanol
                                                                     13                Isoamyl alcohol
            Instrument, Columns and Analytical Conditions
                                                                     13a              Active amyl alcohol
            GC             : GC-2010 with FID                        14                  1-pentanol
            Auto injector  : AOC-5000                                15                   Furfural
            Columns              : Capillary columns are used as below:
                                                                 Results and Discussion
             (1) CP-Wax 57 CB, 50 m L. x 0.25 mm I.D. x 0.20 µm δf (see
            Table 3)                                            The most popular packed column employed for alcohol
             (2) Supelcowax 10, 60 m L. x 0.53 mm I.D. x 1.0 µm δf (see   congeners analysis is the Carbopack B packed with 5% or
            Table 4)                                            6.6% Carbowax 20M [6]. This column provides excellent
             (3) SPB-20, 40 m L. x 0.25 mm I.D. x 1.0 µm δf (Table 5)   peak shape for methanol, resolves methanol from ethanol
             (4) Supel-Q PLOT, 30 m L. x 0.32 mm I.D. (Table 6)  completely and separates two predominant fusel oils
                                                                namely active amyl alcohol and isoamyl alcohol (see
                                                                Figure 1 and Table 2).
