LAAN-A-LC-E293







            Application                  Supercritical Fluid Chromatography

            News
                                         Analysis of Choline and Acetylcholine in
                                         Rat Cerebrospinal Fluid Samples Using the
            No. L519                     Nexera UC-MS/MS System



            Choline, which is a structural element of cell membranes, and
                                                                       Area
            acetylcholine, which is known as a neurotransmitter, are both
            familiar compounds in the  field of bioanalysis. Since   15000000  Choline
            acetylcholine is  biosynthesized in the body from choline, it is
            possible to estimate the quality of internal activity by monitoring   10000000
            both of these compounds. This article focuses on the SFC analysis
            of these compounds in a rat cerebrospinal fluid sample by direct
                                                                 5000000
            injection of the cerebrospinal fluid to the Nexera UC SFC system.
            Also introduced is automatic  extraction and analysis  of a                  r  = 0.9993
                                                                                          2
            cerebrospinal fluid sample impregnated into  filter paper, in   0 0  250  500   750     Conc (μg/L)
            consideration of convenience and durability for storage and
            transport, using the Nexera UC online SFE-SFC-MS/MS system.
                                              Y. Watabe, T. Iida       Area
                                                                100000000

            „  SFC-MS/MS Analysis                                        Acetylcholine
                                                                 75000000
            A CN column provided favorable separation of choline and
            acetylcholine in SFC-MS/MS  analysis. Calibration curves  were   50000000
            created from the peak area values from six times repeated
            analyses for each  of the three concentrations of 10,  100, and   25000000
            1000 μg/L. Good linearity was obtained and the quantitation                  r  = 0.9982
                                                                                         2
            limit (LOQ, ASTM method) was 30 μg/L for choline and 10 μg/L   0         500    750
            for acetylcholine. Table 1 lists the conditions of SFC-MS/MS   0  250                  Conc (μg/L)
            analysis. Fig.  1  shows the structural formula of choline and
            acetylcholine and Fig. 2 shows the obtained calibration curves.   Calibration Curves of Choline and Acetylcholine

                                                               The retention time and peak area repeatabilities after six
                                                               repetitions at each concentration of 10, 100, and 1000 μg/L
                                                               was confirmed at calibration curve creation and the results
                                                                                                2
                                                               are summarized in Table 2. The linearity (r ) was 0.9993 for
                                                               choline and 0.9982 for acetylcholine. Fig. 3 shows the MRM
                           Structure of Choline (Left) and     chromatograms for 100 μg/L.
                            Acetylcholine (Right)
                                                                        Table 2  Repeatabilities of Choline and

                                                                           Acetylcholine Standards (n = 6)
                    Table 1  SFC-MS/MS Analytical Conditions
                                                                                       Retention time   Peak area
             Column        :  Inertsil CN-3    250 mm L. × 4.6 mm I.D., 5 μm             (%RSD)      (%RSD)
             Mobile phase   :  A) Supercritical fluid of CO2    Choline          10 μg/L      0.22        7.5
                            B) Modifier: Methanol containing 20 mmol/L
                            ammonium formate / water =95/5 (v/v)  Choline       100 μg/L      0.05        1.7
             Time program   :  B Conc. 10 % (0 min) → 25 % (10 min) →  Choline  1000 μg/L     0.07        2.2
                            50 % (10.1-12 min) → 10 % (12.1-15 min)
             Flow rate     :  2.5 mL/min                        Acetylcholine    10 μg/L      0.07        5.7
             Column temp.   :  40 °C                            Acetylcholine   100 μg/L      0.06        4.2
             Injection volume   :  1 μL                         Acetylcholine  1000 μg/L      0.07        6.0
             BPR pressure   :  10 Mpa
             BPR temp.    :  50 °C
             Detector      :  LCMS-8050 (ESI, MRM mode)             (×1,000,000)
             Make-up      : Methanol                              1.5
             Make-up flow rate   :  0.2 mL/min
             MRM transitions   :  (+) m/z 104.1>60.1 (for choline)
                            (+) m/z 146. 1>87.1 (for acetylcholine)  1.0

                                                                                            Choline
                                                                  0.5       Acetylcholine

                                                                  0.0
                                                                    0.0         5.0        10.0       min

                                                                       Choline and Acetylcholine Standards (100 μg/L)
