Excellent System Expandability

System Configuration Applicable

to a Variety of Applications

Solvent Delivery Unit Accommodates a Wide Range of Recovery Volumes

Guidelines for Preparative Scale and Maximum Load

The figure at right shows the guidelines 3 mg 20 mg 300 mg 2 g
3 mg
2 g
20 mg
300 mg
for total component capacity with a Typical Maximum
Load (Single Injection,
Analytical
Semi-micro
250 mm long column when the target Column Length of Semi-micro Analytical Semi-preparative PreparativeSemi-preparative Preparative
5 mm I.D.
50 mm I.D.
20 mm I.D.
2 mm I.D.
component is highly soluble in the 25 cm) 2 mm I.D. 5 mm I.D. 20 mm I.D. 50 mm I.D.
mobile phase, separates from impurities,
and ions are suppressed. For isocratic
elution, in principle, the total
0.1
0.001
0.01
10
100
component capacity is proportional to Flow Rate (mL/min) 0.001 0.01 0.1 1 1 10 100
the column volume. LC-40D 10 mL/min
LC-20AR 20 mL/min
LC-20AP
150 mL/min
Supports a Range of Applications
from High-Precision Analytical to Semi-Preparative
LC-40D • This solvent delivery unit can handle flow rates ranging from those used in analytical
scale to those used in semi-preparative (up to 10 mL/min).
• High-precision analysis is possible even in the semi-micro flow-rate range.
Supports Semi-Preparative and Recycle Preparative
LC-20AR • This solvent delivery unit can handle flow rates used in semi-preparative scale (up to 20
mL/min).
• Using a recycle kit enables semi-preparative recycling.
Supports Large-Scale Preparative Fractionation
LC-20AP • High flow rates (up to 150 mL/min) enable highly efficient, large-scale preparative
fractionation.
• Large-scale prep solvent delivery fully supports the preparative fractionation workflow,
including reinjection, to assess purity.
• Combine with an FCV-200AL low-pressure gradient unit to perform gradient analysis
using up to four mobile phases.
Speci cations
LC-40D LC-20AR LC-20AP
Solvent Delivery Method Parallel-type double plunger
Plunger Capacity 10 µL 47 µL 250 µL
Maximum Discharge Pressure 44 MPa 49 MPa 42 MPa
0.0001 to 5.0000 mL/min (1.0 to 44 MPa)
Flow Rate Setting Range 0.01 to 20.00 mL/min 0.01 to 150.00 mL/min
5.0001 to 10.0000 mL/min (1.0 to 22 MPa)
Flow Rate Accuracy No more than ±1% or ±2 µL/min, whichever No more than ±1% or ±10 µL/min, No more than ±1% (1 mL/min, 10 MPa)
is greater (under specified conditions) whichever is greater (0.1 to 5.0 mL/min)
Flow Rate Precision No more than 0.06% RSD or 0.02 min SD, No more than 0.08% RSD or 0.02 min SD, No more than 0.1% RSD or 0.02 min SD,
whichever is greater whichever is greater whichever is greater
Constant Pressure Solvent Delivery Supported
Plunger Rinsing Mechanism Optional available Syringe or rinsing pump (228-39625-41) Syringe or rinsing pump (228-39625-41)
Operating Temperature Range 4 to 35°C
Size and Weight W260 × D500 × H140 mm, 10 kg W260 × D500 × H140 mm, 16 kg W260 × D500 × H210 mm, 19 kg
