Excellent System Expandability

System Configuration Responds Flexibly

to Applications

The LH-40 Liquid Handler, Combination of Autosampler and Fraction Collector

Provides Both a Sample Injection Function
and a Fraction Collection Function
A single unit can perform everything from sample injection to fraction recovery.

Suppresses Contamination
A proprietary injection method minimizes carryover, significantly limiting
contamination to subsequent samples.
(When a 4000 mg/L caffeine sample is injected, the carryover is 0.004 % or less.)

Capable of Injection from a Variety of Containers
With its long needle stroke, the system is compatible with containers of varying
depths, including microtiter plates (MTP), vials, test tubes, and sample bottles.

Options
Syringe Kit 20 mL Liquid Surface Detection Needle

This kit enables large-capacity injections of 2 mL or more at This detects the liquid surface level, and automatically
one time. The maximum injection volume is 20 mL. determines whether there is any sample present. As a result,
only the remaining volume is injected, which prevents the
Washing Pump injection of air into columns. Additionally, if no sample is
present, the system can proceed to the next sample, reducing
This reduces the washing time for the injection needle,
increasing throughput while reducing carryover. needless errors and lost labor.
Multi-Liquid Handler Kit * 3 Analysis Kit

Up to six LH-40 liquid handlers can be connected, making it The recovered fraction can be reanalyzed to check the purity.
easy to inject the sample from all LH-40.
*3 Up to one LH-40 when FRC-40 fraction collectors are connected.
Autosampler Manual Injector
®
SIL-10AP Rheodyne 7725
Sample Racks Optional Sample Loops (Material: SUS)

Sample Coolers
(Block Cooling/Heating: 4 to 70°C)

Speci cations
LH-40 SIL-10AP
Maximum Injection Volume Up to 2 mL, up to 20 mL (Optional available) Up to 5 mL
Cooling Function None Yes (Optional available)
10 mm O.D. test tube 540 pcs 1.5 mL vial 486 pcs* 4
12 mm O.D. test tube 486 pcs 4.0 mL vial 252 pcs
13 mm O.D. test tube 360 pcs 13 mL vial 108 pcs 1.5 mL vial 100 pcs
Compatible Containers and 15 mm O.D. test tube 252 pcs 50 mL vial 54 pcs 4.0 mL vial 80 pcs
Quantities
17, 18 mm O.D. test tube 216 pcs 250 mL bottle 20 pcs 13 mL vial 25 pcs
25 mm O.D. test tube 108 pcs 500, 1000 mL bottle 12 pcs
30, 35 mm O.D. test tube 54 pcs 96 well MTP/DWP 9 pcs
Size and Weight W 390 × H 560 × D 730 mm, 40 kg W 260 × H 280 × D 320 mm, 18.5 kg
*4 Available for injection sample container. Not available for fraction container.

18
