P. 52

No. SSI-HPLC-037






                                          High Performance Liquid Chromatography
                                          Extraction and LC-MS/MS

                                          Analysis of PFAS Compounds in Fish
                                          Tissue Using Offline Supercritical Fluid

              No. HPLC-037



               ■ Introduction
               Per and Poly-fluoroalkyl substances (PFAS) are     Optimized extraction conditions to maximize PFAS
               synthetic compounds that are found in a wide range   recoveries are shown in Table 1. After extraction, the
               of industrial and consumer products. Due to the    sample was dried down under nitrogen and
               strong nature of the carbon-fluorine bond, these   reconstituted with 1 mL of methanol. The sample
               compounds are resistant to degradation and have    was centrifuged and the supernatant was transferred
               been found to accumulate in fish, wildlife and     to an LC vial. 1 uL of the supernatant was injected
               multiple environmental samples (ex. water, soil…),   for LC-MS/MS analysis. Table 2 shows the LC-MS/MS
               posing a significant health risk to humans. Current   conditions used for the Shimadzu LCMS-8050 for
               sample preparation techniques for PFAS analysis are   this study; a representative chromatogram is
               laborious and not easily automated. In this study,   included in Figure 2.
               supercritical fluid extraction (SFE) was evaluated as
               an alternative sample preparation technique for the   Table 1: SFE optimized method conditions

               extraction of eighteen PFAS compounds from fish     Item                   Value
               tissue, as a preconcentration step prior to their   Mobile phase           CO2/MeOH
               analysis by LC-MS/MS.                               Modifier concentration   20% MeOH
                                                                   Flow rate              5 mL/min
               ■ Experimental Approach                             Vessel temperature     60 ℃
               For this study, the Shimadzu Nexera UC offline SFE   Extraction cycles     3
               system (configuration shown in Figure 1) was        Back pressure          20 MPa
                                                                                          45 minutes
                                                                   Extraction time
               employed. 0.5 grams of freeze-dried fish tissue was
               milled and mixed with 1 packet (1 gram) of Miyazaki
               Hydro-Protect and placed into a 5 mL extraction
               vessel for extraction.



                                        CO2               SFE          BPR         Gas liquid
                                                                                   separator








                                                                                  Fraction
                                                                                 Collector
                                       Modifier
                                        pump

               Figure 1: System Configuration of offline SFE system for direct collection method.
               CO2: CO2 pump; SFE: Supercritical Fluid Extraction Module; BPR: Back pressure regulator
