Application   No. C184
    News


          Preparation of Samples                                final volume of 1 mL in 96:4% methanol:water after
                                                                adding IS. It is recommended to vortex the LC vials
          Sample preparation and SPE were carried out           prior to injection and analysis by LC-MS/MS to ensure
          according to EPA Method 537. A vacuum manifold with   that all solutions are homogenized and consistent
          a high-volume sampling kit fitted with PEEK tubing was  results are obtained.
          used   to  reduce  potential  PFAS  contamination.
          Extractions were performed using Biotage-ISOLUTE®     LCMS Analytical and Instrument Conditions
          101   polystyrenedivinylbenzne  (SDVB)  cartridges
          (500 mg / 6 mL, Part No. 101-0050-C). Each cartridge  PFAS analyses were carried out by injecting 1 µL of
          was first conditioned with methanol, followed by LCMS-  the extracted aliquot into the Shimadzu LCMS-8045
          grade water. The water sample was first fortified with  and LCMS-8050 with the conditions shown in Table 2
          surrogates and passed through the SPE cartridge.      and Table 3. PFAS compounds, including branched
          Compounds were eluted from the solid phase with       and linear isomers of PFHxS and PFOS, were
          8 mL of methanol and evaporated to dryness using      separated using a Shim-pack™ Velox SP-C18 column.
          nitrogen. Extracted samples were reconstituted to a

                    Table 2. LC System and Parameters              Table 4. Retention times (RT) and MRM transitions
                                                               PFAS Compound      RT (mins)  Precursor Ion  Product Ion
          LC System        :  Nexera™-X2 UHPLC System
                                                               PFBS                 8.046     298.90      80.10*
                             Shim-pack™ Velox SP-C18,                                                      99.10
          Analytical Column  :  150mm x 2.1mm x 2.7µm,         4:2 FTS              8.558     327.00      80.90*
                             Part No. 227-32003-04                                                        307.00
                             Shim-pack™ XR-ODS II,             PFHxA                8.614     312.90      269.00*
          Solvent Delay                                                                                   119.10
          Column           :  75mm x 2mm x 2.2µm,
                             Part No. 228-41605-93             M2PFHxA (Surr.)      8.650     315.00      270.00*
                                                                                                          79.90*
          Column Temp.     :  40  C                            PFPeS                8.666     348.90       98.90
                                o
                                                                                                          319.00*
                                                               PFHpA                9.512     362.90
                                                                                                          169.00
          Injection Volume   :  1 µL #                                                                    80.10*
                                                               PFHxS                9.558     398.90
                                                                                                           99.10
                                                                                                          406.90*
                                                               6:2 FTS
                                                                                              427.00
                                                                                   10.770
          Mobile Phase     :  A: 20 mM Ammonium Acetate                                                    80.00
                             B: Methanol                                                                  369.00*
                                                               PFOA                10.840     412.90
                                                                                                          169.00
          Flow Rate        :  0.25 mL/min                      PFHpS               10.859     448.90      79.90*
                                                                                                           98.90
                                                               M2PFOA (IS)         10.877     415.00      370.00*
          Run Time         :  35 minutes                                                                  418.90*
                                                               PFNA                12.545     462.90      219.00
         #  A much lower injection volume was used as compared to the injection                           80.10*
         volume of 10 µL in EPA Method 537.                    PFOS                12.550     498.90       99.10
                                                               M4PFOS (IS)         12.575     503.00      80.00*
                  Table 3. LCMS Acquisition Parameters
                                                               8:2 FTS             14.436     526.90      506.90*
          MS Instrument       :  LCMS-8045 and LCMS-8050                                                   80.90
                                                               PFNS                14.469     548.90      79.90*
                                                                                                           98.90
          Interface           :  Electrospray Ionization (ESI)
                                                               M2PFDA (Surr.)      14.484     515.00      469.95*
                                                                                                          468.90*
          Interface Temp.     :  300  C                        PFDA                14.486     512.90      219.00
                                    o
                                                               M-N-MeFOSAA (IS)    15.403     572.90      419.00*
          Desolvation Line Temp.  :  100  C                                                               419.00*
                                    o
                                                               N-MeFOSAA           15.423     569.90
                                                                                                          482.90
                                    o
          Heat Block Temp.    :  200  C                        M-N-EtFOSAA (Surr.)  16.357    588.90      419.00*
                                                                                                          79.90*
                                                               PFDS                16.397     598.90
                                                                                                           98.90
          Heating Gas Flow    :  15 L/min                                                                 419.00*
                                                               N-EtFOSAA           16.411     583.90
                                                                                                          482.90
          Drying Gas Flow     :  5 L/min                       PFUnA               16.449     562.90      519.00*
                                                                                                          269.00
                                                                                                          568.90*
                                                               PFDoA               18.339     612.90
          Nebulizing Gas Flow  :  3 L/min                                                                 169.00
                                                               PFTriA              20.035     662.00      618.90*
                                                                                                          169.00
          Total MRMs          :  48                            PFTreA              21.549     712.90      668.90*
                                                                                                          169.00
                                                               * Quantifying ions
