Page 15 - Hydrocarbon Evaluation Rubber and Plastic

BW-K/BX-K Series
Built-in calibration GLP/GMP/ISO
Model Capacity Minimum display Windows Direct
weight calibration report
BW12KH 12kg 0.1g ● ● ●
BW22KH 22kg 0.1g ● ● ●
BW32KH 32kg 0.1g ● ● ●
BW32KS 32kg 1g ● ● ●
BW52KS 52kg 1g ● ● ●
BX12KH 12kg 0.1g ● ●
BX22KH 22kg 0.1g ● ●
BX32KH 32kg 0.1g ● ●
BX32KS 32kg 1g ● ●
BX52KS 52kg 1g ● ●
BW-K/BX-K Series
Large capacity with fine readability offer various possibility for industries. Weighing precious materials in bulk, efficient but precise
compounding, confirming small parts not missing in a large assembly, etc. UniBloc technology gives fast response, display stability and
endurance, all of which are essential for large capacity industrial balances. Auto print, WindowsDirect and various productivity functions are
ready for use as standard features. BW-K has a large-size built-in calibration weight to ensure utmost accuracy.
AW/AX/AY Series
Motor-driven GLP/GMP/ISO
Model Capacity Minimum display PSC Clock-CAL Windows Direct
calibration weight calibration report
AW320 320g 0.1mg ● ● ● ● ●
AW220 220g 0.1mg ● ● ● ● ●
AW120 120g 0.1mg ● ● ● ● ●
AX200 200g 0.1mg ● ● ●
AX120 120g 0.1mg ● ● ●
AY220 220g 0.1mg ●
AY120 120g 0.1mg ●
AW/AX/AY Series
Equipped with the WindowsDirect function, enabling measurement data to be transferred to any Windows application with just one cable.
Spacious weighing chamber provides ease in weighing any objects. AW/AX series are equipped with a motor-driven calibration
weight, which makes it fairly easy to maintain weighing accuracy all the time. AW series also offers two types of fully-automatic span calibration
functions. PSC is based on temperature detection, and Clock-CAL, is performed at user pre-set times of the day. GLP/GMP/ISO-compliant
calibration report can be automatically output, supported by the built-in clock (AW/AX series).

BL Series
Model Capacity Minimum display Description
BL220H 220g 0.001g
BL320H 320g 0.001g
BL2200H 2200g 0.01g
BL3200H 3200g 0.01g
BL3200HL 3200g 0.01g Display backlight
BL320S 320g 0.01g
BL620S 620g 0.01g
BL Series BL3200S 3200g 0.1g
Compact and affordable, though, high accuracy that is brought by the electro-magnetic system is the same as analytical balances'. Their quick
response is appreciated particularly in production and quality control sites. Unit conversion, percentage conversion and piece counting are
standard features. BL3200HL model is equipped with display back light.

EL Series ELB Series
Minimum Rechargea ble Dry battery Minimum Rechargea ble Dry battery
Model Capacity display battery (option) operation (standard) Model Capacity display battery (option) operation (standard)
EL120 120g 0.01g ● N/A ELB120 120g 0.01g N/A ●
EL200 200g 0.01g ● N/A ELB200 200g 0.01g N/A ●
EL300 300g 0.01g ● N/A ELB300 300g 0.01g N/A ●
EL600 600g 0.05g ● N/A ELB600 600g 0.05g N/A ●
EL600S 600g 0.1g ● N/A ELB600S 600g 0.1g N/A ●
EL1200 1200g 0.1g ● N/A ELB1200 1200g 0.1g N/A ●
EL2000 2000g 0.1g ● N/A ELB2000 2000g 0.1g N/A ●
EL3000 3000g 0.1g ● N/A ELB3000 3000g 0.1g N/A ●
EL6000S 6000g 1g ● N/A ELB6000S 6000g 1g N/A ●
EL/ELB Series EL12K 12000g 1g ● N/A ELB12K 12000g 1g N/A ●
Handy low cost balances, but there is no compromise in accuracy. Reliable strain-gauge load cell brings resolution up to 30,000. One-second
response comes with accuracy and stability. Piece counting, percentage, unit conversions and specific gravity software are all standard
features. Now all these advantages are available with dry battery operation (ELB). Easy battery replacement feature and long battery life make
this series the most user-friendly balances for field use.

15 Mass Evaluation
