Electric-Hydraulic Dynamic and Fatigue Testing System
EHF-U Series
Civil Engineering,
Automobiles Steel, Metals, Machines Construction R&D
For Full-Scale Fatigue and Endurance Testing of EHF Series Electric Hydraulic Dynamic and Fatigue Testing System
Structural Materials and Large Samples
By providing a T-slot surface plate at the bottom of a U-type loading frame with a top-mounted actuator, these systems allow installation of extra
large components and parts. Due to the large testing space, dynamic testing and evaluation can be performed on a variety of samples, including
full-size samples and structural members.
Rated Actuator Capacities of
50 kN, 100 kN, and 200 kN Support
a Wide Range of Dynamic Testing
Top-Mounted Actuator EMT/NJ-SERVO/MMT Series Electric Fatigue and Endurance Test System
Supports dynamic and endurance testing of full-size samples, large components, Hydraulically
and structural members. lifting/lowering crosshead
±0.5 % test force accuracy
Test force accuracy is guaranteed to within ±0.5 % of the indicated value.
High Rigidity and Large Testing Space
A T-slot surface plate makes it easy to secure samples. Servo Controller 4830 Controller for Dynamic and Fatigue Testing Systems
The size of the surface plate and length of the columns can be customized High-accuracy column
based on the size of samples.
Crosshead drive handle Various Dynamic Testing Systems
Crosshead Drive System with
Operating Error Prevention Mechanism
The hydraulic crosshead drive and hydraulic clamp can be operated intuitively
using the handle.
