Analysis with Individual Temperature Control of Multiple Columns (Multi-Oven Function)
The improved functions of the LabSolutions* workstation support up to four column ovens per system.
This allows analysis with individual temperature control of two columns.

40°C temperature control Individual temperature control at 40°C and 25°C
mV mV
25.0 3 Unseparated 20.0 3 Improved separation * Use the following versions
8 17.5
2 LC/GC Ver. 5.54 SP2
20.0 9
5 15.0 DB Ver. 6.11 SP1
2 5
15.0 12.5 CS Ver. 6.11 SP1
6
10.0 6 9
4
10.0 4
7.5 8
1 7 10 11 1 7 10
5.0 12 5.0 11 1: Phosphoric acid 7: Lactic acid
2.5 12 2: α-ketoglutaric acid 8: Formic acid
0.0
0.0 3: Citric acid 9: Fumaric acid
−5.0 −2.5 4: Pyruvic acid 10: Acetic acid
−5.0 5: Malic acid 11: Levulinic acid
−10.0 6: Succinic acid 12: L-pyroglutamic acid
10.0 12.5 15.0 17.5 20.0 22.5 25.0 27.5 30.0 min
10.0 12.5 15.0 17.5 20.0 22.5 25.0 27.5 30.0 min
25°C temperature control
mV
20.0
3
17.5 Column Shim-pack SCR-102H (two connected)
15.0 Unseparated
2 Solvent 5 mmol/L p-toluenesulfonic acid
12.5 5
9
10.0 6 10 Flow rate 1.0 mL/min
7.5 4
1 7 8
5.0
11
2.5 12
0.0
−2.5
−5.0
10.0 12.5 15.0 17.5 20.0 22.5 25.0 27.5 30.0 min
Built-In Flow-Line Selection Valves
The CTO-20A/20AC can incorporate up to two flow-line selection valves, a manual injector, and a gradient mixer.
The CTO-30A can also incorporate a flow-line selection valve and gradient mixer.
Incorporation of Flow-Line Selection Valve
Mixer
Flow-line selection valve

Manual injector

The FCV-12AH/14AH/32AH/34AH
high-pressure flow-line selection valve
can be incorporated and controlled.
Position display is also possible.
