Easy Mode Analysis Automates All Processes （幅215mm）

Up to Report Generation

Select from three courses according to the target application.
Easy Mode Analysis executes a sequence of qualitative analysis, mapping analysis and report
generation automatically with easy setup of conditions.
Select from three courses according to the target application and experience of the operator.

User operation
Automatic

Select course

Automatic Qualitative Automatic Qualitative Analysis Step-by-Step Qualitative Analysis
Analysis Mode + Mapping Analysis Mode + Mapping Analysis Mode

Designate qualitative analysis position and beam size.

Designate region for mapping analysis.

Start analysis.

Run qualitative analysis.

Qualitative
data processing

Mapping elements automatically
selected from qualitative
processing results; mapping
analysis starts. Confirm
mapping elements.

Run mapping analysis.

Generate analysis reports.
