Shim-pack UC-Diol II Shim-pack UC-Sil II Shim-pack UC-Choles Shim-pack UC-PBr
Bonded Phase Diol Group - Cholesteryl Groups Pentabromobenzyl Group
Particle Size (μm) 3, 5 3, 5 3, 5 3, 5
Pore Size (nm) 12 12 12 12
Surface area (m /g) 340 (3μm), 300 (5μm) 340 (3μm), 300 (5μm) 340 (3μm), 300 (5μm) 340 (3μm), 300 (5μm)
2
Carbon Loading (%) - - 20 8
Pressure Tolerance (MPa) 50 (3μm), 30 (5μm) 50 (3μm), 30 (5μm) 50 (3μm), 30 (5μm) 50 (3μm), 30 (5μm)
Pore volume (mL/g) 1.00 (3μm), 0.90 (5μm) 1.00 (3μm), 0.90 (5μm) 1.00 (3μm), 0.90 (5μm) 1.00 (3μm), 0.90 (5μm)
End-capping - - Yes Yes
pH Range 2 - 7.5 - 2 - 7.5 2 - 7.5
USP Code L20 L3 L101 -

Shim-pack UC-PyE Shim-pack UC-HyP Shim-pack UC-Py Shim-pack UC-Triazole
Bonded Phase Pyrenylethyl Group 3-Hydroxyphenyl Group Pyridinyl Group Triazolyl group
Particle Size (μm) 3, 5 3, 5 3, 5 3, 5
Pore Size (nm) 12 12 12 12
Surface area (m /g) 340 (3μm), 300 (5μm) 340 (3μm), 300 (5μm) 340 (3μm), 300 (5μm) 340 (3μm), 300 (5μm)
2
Carbon Loading (%) 18 - - -
Pressure Tolerance (MPa) 50 (3μm), 30 (5μm) 50 (3μm), 30 (5μm) 50 (3μm), 30 (5μm) 50 (3μm), 30 (5μm)
Pore volume (mL/g) 1.00 (3μm), 0.90 (5μm) 1.00 (3μm), 0.90 (5μm) 1.00 (3μm), 0.90 (5μm) 1.00 (3μm), 0.90 (5μm)
End-capping Yes Yes Yes -
pH Range 2 - 7.5 - - 2 - 7.5
USP Code - - - L104

Analysis Examples

Multiple Pesticides with a Wide Polarity Range
Simultaneous analysis of multiple pesticides with a wide polarity range from hydrophobic to hydrophilic has been achieved using the
Nexera UC and Shim-pack UC RP. Shim-pack UC RP contains a polar functional group embedded between the silica surface and the
C18 group. This allows the column to analyze a wide range of components from hydrophobic to hydrophilic ones.
Simultaneous analysis of multiple components can now be performed more efficiently using the Nexera UC and Shim-pack UC series.
No. Components log P
1 Carbofuran 7.4
2 Ethofenprox 6.9
3 Fenpropathrin 6.0
4 Pyriproxyfen 5.0
5 Pyraclostrobin 4.0
6 Linuron 3.0
7 Aminocarb 1.9
8 Ethoxysulfuron 1.0
9 Halosulfuron methyl 0.0
10 Bentazone –0.5
11 Chlorsulfuron –1.0
12 Rimsulfuron –1.5
13 Nicosulfuron –1.8
14 Vamidothion –4.2
