P.10
Autosamplers SIL-20A / 20AC / 20AHT / 20ACHT
SIL-20A (228-45006-XX) SIL-20AHT (228-45119-XX)
Injection method Total-volume sample injection, variable injection volume
Maximum operating pressure 20 MPa 35 MPa
0.1 to 100 μL (standard)
Injection-volume setting range
0.1 to 2,000 μL (option)
175 (1 mL vials), 105 (1.5 mL vials), 50 (4 mL vials)
Number of processed samples 192 (two 96-well MTP/DWP), 768 (two 384-well MTP/DWP)
Also, ten 1.5 mL vials in addition to each of the above.
Injection-volume accuracy 1% max (specified conditions)
Injection-volume precision RSD: 0.3% max. (specified conditions, typically 0.2% RSD max)
Sample Carryover 0.005% max. (specified conditions, typically 0.0025% max)
Number of repeated injections 30 max. per sample
Needle rinsing Set freely before and after sample injection.
Sample cooler None
Operating pH range pH1 to pH14
Operating temperature range 4 to 35°C
Dimensions, weight W260 × D500 × H415 mm, 27 kg
Power requirements AC 110 V, 230 V, 100 VA, 50/60 Hz
SIL-20AC (228-45007-XX) SIL-20ACHT (228-45120-XX)
Injection method Total-volume sample injection, variable injection volume
Maximum operating pressure 20 MPa 35 MPa
0.1 to 100 μL (standard),
Injection-volume setting range
I
0.1 to 2,000 μL (option)
175 (1 mL vials), 70 (1.5 mL vials), 50 (4 mL vials)
Number of processed samples 192 (two 96-well MTP/DWP), 768 (two 384-well MTP/DWP)
Also, ten 1.5 mL vials in addition to each of the above.
Injection-volume accuracy 1% max (specified conditions)
Injection-volume precision RSD: 0.3% max. (specified conditions, typically 0.2% RSD max)
Sample Carryover 0.005% max. (specified conditions, typically 0.0025% max)
Number of repeated injections 30 max. per sample
Needle rinsing Set freely before and after sample injection.
Sample cooler Block cooling/heating, used together with defumidifying function, 4 to 40°C
Operating pH range pH1 to pH14
Operating temperature range 4 to 35°C
Dimensions, weight W260 × D500 × H415 mm, 30 kg
Power requirements AC 110 V, 230 V, 300 VA, 50/60 Hz
*Prominence UFLC system uses SIL-20A HT UFLC version (228-45132-xx) or SIL-20AC HT UFLC version (228-45133-xx), which has outlet piping optimized for UFLC in standard SIL-20A or SIL-20AC.
P.10
Rack Changer
Rack Changer II (228-45164-XX)
Compatible plates 96-well MTP, 96-well DWP, 384-well MTP, 384-well DWP, 1.5 mL vial plate (54 vials)
Number of processed plates 12
Sample cooler Block cooling/heating, used together with dehumidifying function, 4 to 40°C
Operating temperature range 4 to 35°C
Dimensions, weight W425 × D500 × H415 mm, 32 kg
Power requirements AC 110V, 230V, 350VA, 50/60Hz
33
High Performance Liquid Chromatograph
