The IRTracer-100’s interferometer is optimized and stabilized using a combination of a smooth moving mirror system and the Advanced
            Dynamic Alignment. To assure that the IRTracer-100 is always in the optimum operating condition, a self diagnoses routine monitors
            the operation of the system at initialization and constantly during operation In addition, standard EP/CHP/JP/USP/ASTM validation
            programs are provided to evaluate the FTIR performance.




              Incorporation with Advanced Dynamic Alignment


            Achieving reproducible optical interference in a   and stable quality spectra after only a short warm-up time.
            spectrophotometer requires a robust interferometer design.   Sampling at over 5000 times/second the Advanced Dynamic
            The interferometer in the IRTracer-100 easily meets this   Alignment keeps the IRTracer-100 in optimum operating
            requirement. The smooth moving mirror system monitored by   condition. In addition, the Advanced Dynamic Alignment system
            the Advanced Dynamic Alignment (Japanese Patent No.   automatically aligns the interferometer when the beam splitter
            3613171) system allows the IRTracer-100 to provide optimum   is changed for NIR or FIR analysis.






                               Laser detector                                      Light source


                               He–Ne laser








                                                                                    Moving mirror
                                                                                     Beam splitter
                               Detector
                                                                                      Fixed mirror









                                       Four Bene ts of Advanced Dynamic Alignment


              Removes the in uence       Allows the FTIR to be     Shorter warm-up             Provides for
                 of environmental     powered off when not in use*    times and             a maintenance-free
                    variations         ( saving electricity and reducing  (  enhanced stability  system
                                         the environmental impact

               Scheme of Advanced Dynamic Alignment

             1                   2                   3                    4  The difference   5   The inclination of
                The interference                         The calculated      between these
                  pattern of         The quality of   interference is compared                   the  xed mirror is
               the He–Ne laser light  the produced     with stored patterns  interference patterns  continuously adjusted to
                                                                             is calculated by
                 is detected by      interference    obtained under optimum                   eliminate any difference and
               the Laser Detector.   is calculated.    operating conditions.  an advanced     maintain optimum operating
                                                                           digital signal processor.  sampling conditions.

                                                                                             * Automatic Dehumidi er is working.
