Screening Analysis Kits (Option)

Ideal for RoHS, ELV, and Halogen Screening Automatic Measurement Time Reduction
The optional screening analysis kits allow even beginners to start RoHS, halogen, or antimony screening analysis right from the day of purchase. This function automatically switches to the next analysis channel if a Concentration
Simply mount the sample, select the analysis conditions, enter the sample name, and wait for the results. The analysis results are displayed with controlled substance clearly has a high or low concentration, making
a pass/fail evaluation after just a few minutes. evaluation possible while measurement is underway. This achieves
Above control standard
more efficient screening analysis.

Clearly above the control standard, so measurement is cut off.
Gray zone. Measurement proceeds for the set time. Standard value Gray zone
Clearly below the control standard, so measurement is cut off.

Below control standard

Screening Simple Setup Screen

Threshold Values
A threshold value can be set for each material and element. The screening
evaluation method changes according to how the threshold values are set.
Evaluation Character String
Character strings can be set for display in the analysis results when the
threshold value is not exceeded, in the gray zone, and when the threshold
value is exceeded.
Report Template
Set the report style from among the templates supplied as standard.

Simple Setup Screen of RoHS Screening Analysis Kit
Analytical results window using the RoHS, Halogen and Antimony screening kit
Three screening Analysis kits are available to suit different applications.

Internal Calibration Curves and Automatic Calibration Curve Selection RoHS Screening Analysis Kit
Kit for screening cadmium, lead, mercury, chromium, and
Internal calibration curves PE bromine. Polyethylene samples containing these five elements
1.4
Internal calibration curves are provided for many materials, making it are supplied in the kit for instrument management.
unnecessary to provide a large number of standard samples. 1.2 RoHS and Halogen Screening Analysis Kit
Automatic calibration curve selection 1.0 PVC In addition to cadmium, lead, mercury, chromium, and bromine,
The software automatically selects the best calibration curve for the material, Measured intensity ratio 0.8 Aluminum this kit also supports the screening of chlorine in plastics.
freeing the user from the need to select analysis conditions. 0.6 Polyethylene samples containing these six elements are supplied
in the kit for instrument management.
As an incorrect calibration curve selection can result in large error in the Steel
quantitation results, this function contributes to improved data reliability. 0.4 Brass RoHS, Halogen, and Antimony Screening Analysis Kit
0.2 In addition to cadmium, lead, mercury, chromium, and bromine,
Shape correction Solder
this kit also supports the screening of chlorine and antimony in
0.0
The fluorescent X-ray and scattered X-ray intensities are compared for each 0.0 20.0 40.0 60.0 80.0 100.0 plastics. Polyethylene samples containing these seven elements
element (BG internal standard method) to eliminate the effects of the sample Standard valueʢppmʣ are supplied in the kit for instrument management.
shape and thickness in the quantitation values.
