SHIMADZU | WHITE PAPER                             Ultra-fast LC-MS/MS Analysis of PFAS in Environmental Waters



             PFAS Stability Study – Effects of Solvents, LC      Calibration Range and Method Detection Limit
              Vial Materials and Vortex                           (MDL)
          The shelf life of the prepared PFAS standards was   Calibration was performed for all PFAS compounds
          evaluated using the following solvents: 10%, 30%,   using a nine-point calibration curve, ranging from
          50%, 70% and 90% methanol, in both glass and        5 ng/L – 200 ng/L with some exceptions. FHEA, FOEA
          polypropylene vials. The plots of relative intensity of   and FDEA, the fluorotelomer acids, were calibrated in
          PFAS against shelf life (time/hours) shown in Figure 3   the range of 100 – 4000 ng/L. The linearity of the
          demonstrate that the 50% methanol in water used in   curves was evaluated using 1/x weighting, ignoring the
          the ASTM methods sufficiently dissolves the PFAS    origin. The calibration range are shown in Table 4 and
                                                                                                            2
          compounds and keeps them in solution. The lower     all calibration curves had a regression coefficient (R )
          concentrations of methanol (10% and 30% methanol)   higher than 0.99. The calibration curves and regression
                                                                          2
          show significant loss of PFAS due to the insolubility of   coefficient (R ) of some selected PFAS compounds are
          PFAS in the solvent used. The recovery results for 90%   illustrated in Figure 5.
          methanol are similar to that of 70% methanol.
                                                              A MDL study was conducted by spiking the water
          Furthermore, the materials of the LC vial, amber glass   samples (5 mL). FHEA, FOEA and FDEA were spiked
          and polypropylene, were investigated to determine the   at a concentration of 100 ng/L; the rest of the PFAS
          potential adsorption of PFAS on the vial surface Similar   compounds were spiked at 20 ng/L. The
          recovery and quantitation were observed regardless of   MDL, %recovery and % RSD were determined and are
          the material of the LC vials. Rather than the material of   shown in Table 4. The MDLs using the LCMS-8060 are
          the LC vial, the effect of vortex on the recovery of   in the range of 0.6 – 5.4 ng/L for the 44 PFAS
          PFAS is considerable (Figure 4). To demonstrate the   compounds (excluding fluorinated telomer acids).
          importance of utilizing the vortex mixer, a PFAS    Similarly, the % recovery and % RSD for these 44
          standard solution was allowed to sit for 24 hours. An   PFAS were within the acceptable limits (70-130%).
          end mid-level calibration check (50 ng/L) was prepared
          and the recovery of the PFAS compounds from the vial,
          before and after mixing, was determined. Figure 4     Summary and Conclusion
          shows the chromatogram of the PFAS compounds        This white paper summarized and illustrated the use,
          before and after vortex. The recovery of the long-chain   performance and compatibility of Shimadzu UFMS for
          PFAS is noticeably lower before vortex. The use of   the analysis of PFAS in environmental samples. With
          vortex ensures that the solution is homogenous and   reference to ASTM D7979, 49 PFAS compounds were
          consistent results are obtained.                    separated and quantified with a simple direct injection
          The PFAS concentration in the vial may change after   method and rapid LC-MS/MS analysis (LCMS-8060).
          the vial cap is pierced as the organic solvent (i.e.   Direct injection without SPE allows for maximum
          methanol:water solution) and/or PFAS compound can   throughput and minimal background, loss and
          be lost through the puncture. If calibration standards   contamination cause by sample preparation. The high-
          are to be used multiple times, it is recommended to use   speed and high-sensitivity characteristics of the LCMS-
          amber glass vial with sealed replaceable caps. This   8060 achieve a method detection limit of 0.6 – 5.4 ng/L
          sealing of vials immediately after injection may alleviate   and recovery of 84 – 113% for all PFAS compounds,
          the loss of PFAS.                                   excluding FTAs. These results fall within the quality
                                                              control requirements and limits. Together with a high
                                                              scanning speed and a short dwell time, the Shimadzu
                                                              LCMS-8060 achieves rapid, reliable and highly
                                                              sensitive quantitation of PFAS in environmental waters.
