Balances

Analytical Balances Analytical Balances
AU Series AT-R Series

These balances are capable of speedy measurements, with a high-speed Even though they are low-cost models, the AT-R Series equipped with
3 second display. They are equipped with automatic calibration for the same “UniBloc” technology found in high-end models. They feature
room temperature changes, and clock-CAL for calibration at pre-set highly stable performance, and are capable of highly reliable weight
times, and are capable of direct data readout to Excel and other measurements even with extended use. Also equipped with a “smart
applications. setting” that can freely switch between responsiveness and stability
Model Capacity Minimum Display during measurement, and two interfaces, RS-232C and USB device. The
AUW120D 42 g/120 g 0.01 mg/0.1 mg connectivity of external devices such as PCs has been further improved.
AUW220D 82 g/220 g 0.01 mg/0.1 mg Model Capacity Minimum Display
AUW120 120 g 0.1 mg ATX84R 82 g 0.1 mg
AUW220 220 g 0.1 mg ATX124R 120 g 0.1 mg
AUW320 320 g 0.1 mg ATX224R 220 g 0.1 mg
AUX120 120 g 0.1 mg ATX324R 320 g 0.1 mg
AUX220 220 g 0.1 mg ATY64R 62 g 0.1 mg
AUX320 320 g 0.1 mg ATY124R 120 g 0.1 mg
AUY120 120 g 0.1 mg ATY224R 220 g 0.1 mg
AUY220 220 g 0.1 mg ATY324R 320 g 0.1 mg
Brochure No. C054-E032 Brochure No. C054-E032

Electronic Balances
UP Series

This is a top-loading balance with the world's fastest class reaction
speed. With a cutting-edge digital control technology, their response
time when measuring trace quantities has been shortened to
approximately 1 second (1/9 of the conventional level), and it greatly
increases the weighing operation efficiency. In addition, it uses a highly
durable weight sensor “UniBlock” that has passed 1 million endurance
tests (10 times the test standard under the Measurement Act), making
it safe to use in various weighing situations. Models with a capacity of
2200 g or more are equipped with a newly designed “UP-Wind Break”
as standard to reduce the effects of wind from air conditioners, etc. In
UP6202X Bucket for small animals
addition, by attaching an optional animal bucket set and setting the
main body to animal measurement mode, it can be used as an animal
balance.

UP-X Series (with built-in calibration weight) UP-Y Series
Model Capacity Minimum Display Model Capacity Minimum Display
UP223X 220 g 0.001 g UP223Y 220 g 0.001 g
UP423X 420 g 0.001 g UP423Y 420 g 0.001 g
UP623X 620 g 0.001 g UP623Y 620 g 0.001 g
UP823X 820 g 0.001 g UP823Y 820 g 0.001 g
UP1023X 1,020 g 0.001 g UP1023Y 1,020 g 0.001 g
UP2202X 2,200 g 0.01 g UP2202Y 2,200 g 0.01 g
UP4202X 4,200 g 0.01 g UP4202Y 4,200 g 0.01 g
UP6202X 6,200 g 0.01 g UP6202Y 6,200 g 0.01 g
UP422X 420 g 0.01 g UP422Y 420 g 0.01 g
UP822X 820 g 0.01 g UP822Y 820 g 0.01 g
UP4201X 4,200 g 0.1 g UP4201Y 4,200 g 0.1 g
UP8201X 8,200 g 0.1 g UP8201Y 8,200 g 0.1 g
Brochure No. C054-E076
