Application  No.T152
    News


            Q Measurement of Tripalmitin                          DSC
                                                                  mW
            Tripalmitin is also known to be polymorphic. In Fig. 4,
            the melting peak seen at 61.6 ˚C during the first run    1st run
            corresponds to melting of stable crystal form Ќ.     5.00          42.5 ˚C
            Next, an exothermic peak at 42.5 ˚C is seen during the                            heat of fusion: -183.6 J/g
            cooling process. This peak equates to crystallization of             heat of fusion: 122.3 J/g
            quasi-stable crystal form  Ћ. The exothermic/                                  61.6 ˚C
            endothermic peak observed in the region of 45 ˚C to   0.00  Cooling
            58 ˚C during the second run equates to melting of
            form Ћ followed by crystallization of form Ќ. The        2nd run                  heat of fusion: -44.0 J/g
            heat of fusion of form Ќ melting at around 60 ˚C is   -5.00  heat of fusion: -115.4 J/g  60.7 ˚C
            observed to be smaller due to incomplete crystallization
            of form Ќ.                                                            46.5 ˚C
                                                                        30.0  40.0  50.0   60.0  70.0  80.0
                                                                                     Temp [˚C]
                                                                        Fig. 4  DSC Measurement of Tripalmitin

            Q Measurement of a Suppository                        DSC
                                                                  mW
            Fig. 5 shows data from heating (first run), cooling, and
            reheating (second run) of a commercially available        1st run   ˠ          heat of fusion: -111.4 J/g
            suppository drug. The melting peak shapes are different   20.00             22.3 ˚C
            during the first run and second run. This difference is                       28.4 ˚C
            due to a change in the crystal form of triglyceride
            present in the suppository drug caused by the heating   10.00             14.8 ˚C  35.0 ˚C
            method used. Because different crystal forms give rise                       19.6 ˚C   ˡ   Cooling
            to different melting characteristics and cracking                       heat of fusion: 75.8 J/g
            behaviors, optimum heat treatment conditions must be   0.00
            investigated.                                              2nd run   ˠ       heat of fusion: -75.8 J/g


                                                                 -10.00                      33.6 ˚C
                                                                         -20.00  0.00   20.00  40.00   60.00
                                                                                     Temp [˚C]
                                                                       Fig. 5  DSC Measurement of a Suppository
            Q Measurement of Sulfathiazole                        DSC
                                                                  mW
            Fig. 6 shows the results of analyzing sulfathiazole. The   6.00
            peak at 169.8 ˚C is presumed to represent the transition   3.00
            from a quasi-stable phase to a stable phase, and the                  heat of fusion: -26.8 J/g  heat of fusion: -107.0 J/g
            peak at 201.1 ˚C is presumed to be melting of the     0.00
            stable phase.                                                                169.8 ˚C
                                                                  -3.00
                                                                  -6.00
                                                                  -9.00
                                                                 -12.00
                                                                                                 201.1 ˚C
                                                                 -15.00
                                                                     100.00        150.00        200.00
                                                                                     Temp [˚C]
                                                                       Fig. 6  DSC Measurement of Sulfathiazole









                                                                                                     First Edition: Jan. 2017
