Hydrocarbon Processing Industry









            of 0.10% sulfur (m/m) in so-called emission control areas (ECAS).   Details on the theory and fundamentals of EDXRF as an analytical
            The primary stated goal of this new regulation is to improve envi-  technique are provided in Grieken and Markowicz (2001) and are
                                                                              10
            ronmental air quality in and around port cities and areas with high   presented briefly here .
            shipping traffic by minimizing SOx emissions.
                                                               As a technique, EDXRF has many advantages when used for anal-
            There are two ways in which fuel producers or ship owners can   ysis of fuels and oils. Namely, the technique is sufficiently sensitive
            comply with the new regulations. First, refiners and producers of   and can be adapted for multiple element analysis. Also, EDXRF
            fuel oils may process those fuels so that they are stripped of their   instruments tend to be small, requiring minimal benchspace and
            sulfur compounds. Alternatively, ship owners have the option to   laboratory infrastructure.  The analyses carried  out in this study
            retrofit their fleet with SOx scrubbers on their exhaust stacks to   can be performed in a laboratory equipped with electricity and
            minimize emissions to make them equivalent to using compliant   helium gas. A brief comparison of advantages and drawbacks of
            fuels. Either approach puts a significant financial burden on the   common analytical techniques for sulfur in petrochemicals is pro-
            responsible party, whether they be refiners or ship owners.   vided in Table 1.


            Due to these new regulations from the IMO, refiners and fuel produc-  The EDX-7000 operates under the principles of X-ray fluorescence
            ers must now assess fuel oil for its sulfur content to ensure compliance.   that  takes  advantage  of  the  fact  that  the  elements  that  comprise
            Because of its ease of use and minimal sample preparation, energy   a sample each have a unique atomic structure which is conceptu-
            dispersive X-ray fluorescence, (EDXRF) is a preferred method for the   ally diagrammed in Figure 1. An X-ray source is used to bombard
            analysis of sulfur. At concentrations of 0.50% and higher, EDXRF is   a sample with X-ray radiation which excites inner-shell electrons
            sufficiently sensitive for sulfur detection and avoids the challenges as-  to an elevated state. Subsequently, an outer-shell electron relaxes
            sociated with other analytical methods, such as atomic absorption, gas   into the hole left by the ejected electron and, in that process, emits
            chromatography, or combustion methods. In this paper, we describe   energy in the form of an X-ray. The X-ray emission line (e.g., Kα,
            the use of Shimadzu’s EDX-7000 for compliance with the new IMO   Kβ, Lα) depends  on  the shell  from which the  relaxing  electron
                                              8
            standards for marine fuels as well as ASTM D4294  and ISO 8754 . 9  originates and that which it ends up in. The emitted X-ray photon
                                                               energy for each element for each element are unique and can be
                                                               used to identify each element, whereas the abundance of X-rays
                                                               produced correlate to the concentration of that element. The re-
                    Analytical Instrumentation                 sulting spectra consists of the photon energy of  X-rays generated
                        and Considerations                     from the sample (in kiloelectronvolts, keV) and the abundance of
                                                               those X-rays (in counts per second per microampere, cps/µA) and
            The instruments used in this study were Shimadzu EDX-7000 series,   is typically processed by software to interpret elemental composi-
            energy-dispersive X-ray fluorescence (EDXRF) spectrometers.   tion and concentration.



                Table 1. General comparison table of common analytical techniques for sulfur. Note that this list is not exhaustive and other techniques are available.
                 Technique                   Advantages                              Drawbacks
                             • Easy to operate
                                                                      • High detection limits (~10s of ppm)
                             • Minimal sample preparation
                  EDXRF                                               • No speciation information
                             • Minimal laboratory requirements
                                                                      • Solids or liquids only
                             • Multi-element analysis
                             • Quick sample throughput                • No speciation information without LC or GC front end
                  ICP-OES    • Robust for complex matrices            • Low sensitivity at common sulfur emission lines
                             • Simultaneous multi-element analysis    • Higher cost of ownership
                             • Quick sample throughput                • No speciation information without LC or GC front end
                  ICP-MS     • Low detection limits                   • Interferences on predominant sulfur isotope 32S
                             • Nearly simultaneous multi-element analysis  • Higher cost of ownership
                             • Highly sensitive (ppb levels)          • Non-specific to sulfur
                  GC-FPD
                             • GC separations enable speciation analysis  • Matrix signal quenching
                                                                      • Historically complex
                             • Highly sensitive (ppb levels) and specific for sulfur
                  GC-SCD                                              • Only analyzes for sulfurs, other detectors required for
                             • GC separations enable speciation analysis
                                                                       other compounds


                                                                                                                 63
