Page 11 - Shimadzu Dynamic and Fatigue Testing Systems

Extensive Experience in a Wide Variety of Fields Evaluating Strain Rate Dependence

From dynamic testing in automotive, aircraft, train, shipbuilding, healthcare, and construction fields to fatigue testing of materials, Shimadzu has In order to accommodate increasingly sophisticated designs, computers are now being used in
developed various dynamic testing machines for all sorts of fields. Shimadzu's extensive dynamic testing experience is available for consulting design simulation technologies. In particular, to ensure safety with respect to impacts or
with customers. determine the behavior during impact fracture, material property parameters are measured at
speeds experienced during actual operation or the simulated deformation rate. Using these
Dynamic Evaluation of Automotive, Aircraft, Rail, parameters in calculations can contribute significantly to calculation results.
Ship, and Various Other Transportation Equipment High-Speed Impact Testing at Speeds Up to 20 m/sec
Increasing the reliability of transportation equipment used to carry people and This high-speed impact testing system integrates several of Shimadzu's advanced technologies, such as
freight involves a variety of dynamic testing requirements, from various design actuators engineered for high-speed testing and shock-absorbing mechanisms that minimize the effects from
verification work to evaluation of endurance. Shimadzu dynamic testing impact testing, to realize a maximum impact speed of 20 m/sec (72 km/h).
systems can be configured to meet unique customer requirements by
combining various standard models or utilizing customized actuators and
loading frames based on Shimadzu's extensive track record and experience.

High-Speed Impact Testing System
Hydroshot HITS Series

Multiple Jack System on the Railway Rail
System Installed for East Japan Railway Company
Load Testing for Large-Scale Structural Members
The ground strength, bearing capacity of pilings, stability of basic structural
members, etc. are evaluated by applying static and dynamic loads on large
structural members using the Shimadzu Servopulser jack system to determine
the relationship between test force and displacement. For load testing, actuator
endurance and stable control technology are essential.
Shimadzu offers support for a wide range of evaluations, such as evaluating structural
members made with new materials, evaluating the endurance of large-scale
structural members, and inspecting old building structural members.
Loading Test System for Steel Structural Members
For Reducing the Time Required for

Evaluating Implants and Biological Materials Fatigue Testing of Metal Materials and
Implants and other products in the biomedical industry must be subjected to
various design verification testing and endurance evaluation before they can be Gigacycle Fatigue Testing 1000
released to the market. Shimadzu electromagnetic force and pneumatic
Servopulser systems are ideal for clean environments and are capable of highly Now that materials used in products are procured from around the world, it is 20 Hz
accurate testing at low load levels. Therefore, they are used to evaluate the especially important to evaluate the material properties when receiving materials. Electric Hydraulic Servopulser
300 Hz
endurance of knee, hip, and spinal implants or in human kinematic research.
With cycle rates up to 20 kHz, the USF-2000 Ultrasonic Fatigue Testing System is High-Cycle Fatigue and Endurance Testing Machine
able to accelerate fatigue life evaluations of metal materials. This means it can Testing time (hour) 100 1kHz
perform tests of 10 cycles, which would normally take 3.2 years at 100 Hz, in only 10 20 kHz Ultrasonic Fatigue Testing System
10
six days. This exceeds the gigacycle level to achieve ultrahigh efficiency.
1
For example ...
8
Assume a 10 cycle test is performed at 20 Hz and 20 kHz. 0.1
10 6 10 7 10 8 10 9 10 10 10 11
Cycles
Other fatigue testing machine
20Hz 2 months
Dynamic and Fatigue Testing in Controlled
Atmospheres
Servopulser systems can be fitted with an environmental control system that
reproduces loads under high temperature or severe environmental conditions or 1000 Times
under environmental conditions experienced during actual usage. This system Ultrasonic Fatigue Testing System 20kHz 1.5 hours Faster
USF-2000
accommodates a variety of testing requirements, such as testing at high
temperatures, in a vacuum or gas atmosphere, or thermal fatigue testing. Resistance Heat High-Temperature Testing System
