TGA & DTA Options

Thermogravimetric Analyzer Standard Suspended-Type High-Sensitivity Flow controller FC-60A
TGA-50 Series TGA Thermobalance (P/N 346-67995-92: for 120V, -93: for 230V)
Micro and Macro Series of Thermogravimetric The FC-60A ow controller is used to control the ow rate of atmosphere
Analyzers withAdvanced Thermobalance Design gases (of two channels). Since the gas ON/OFF control is performed
according to a temperature program, the atmosphere can be automatically
The TGA-50 series is equipped with a lightweight balance mechanism and
taut band fulcrum. These have outstanding vibration resistance and changed during a measurement.
provide for stable high sensitivity measurements. These instruments have Specifications
an extremely wide applicability range, from measuring large-volume
samples that cannot be measured using TG/DTA systems, or allowing the Primary pressure 0.6MPa max.
use of a variety of sample cell sizes. Flow rate PURGE side: 0~500ml/min (calibrated for N2)
The lineup offers two types to choose from depending on the application: DRY side: 0~500ml/min (calibrated for N2)
the H model for high temperatures, and the 51 model, which is a macro PURGE: 2 IN, 1 OUT
type. Specifications Flow line DRY: 1 IN, 1 OUT
TGA-50, TGA-51 : Ambient to 1000°C Size and weight W 180 × D 200 × H 90mm, approx. 3kg
Temperature range
TGA-50H, TGA-51H: Ambient to 1500°C Power supply 90~130V AC or 210~230 V AC, 100VA
± 20 mg, ± 200 mg (TGA-50/50H)
Taut band Measuring range
± 20 mg, ± 200 mg, ± 2 g, (TGA-51/51H)
Balance beam
Gas inlet (2) Weight Readability 0.1µg
Magnet
Radiation fin Gas inlet (1) Sample mass 1 g including tare (TGA-50/50H)
10 g including tare (TGA-51/51H)
Atmosphere Air and inert gas Sample Sealing Crimp Press SSCP-1
TGA-50/50H W: 173 x D: 550 x H: 500 (mm), 23 kg (P/N 222-13130-91)
Thermocouple Dimensions and weight
Heating furnace TGA-51/51H W: 173 x D: 600 x H: 540 (mm), 25 kg Samples are prepared with various types of pans for Shimadzu thermal analyzers by using the SSCP-1 in combination with the attachment specifically for the
Sample TGA-50 AC 100 V, 120 V, 230 V 1000 VA 50/60 Hz pan to be used (sold separately).
Power supply
TGA-51/50H 1200 VA, TGA-51H 1500 VA
Detailed brochure C160-E012A Attachments
Pan to Be Used P/N Description
TGA
% *1 201-52943 222-13053-91 Crimp attachment
100.1 Al crimp pans
*2 346-66963-91 222-12821-91 Crimp attachment
100.0 -0.167% Al crimp pans (for autosampler)
*3 201-53090
222-13175-93 222-12826-91 Hermetic attachment
99.9 Al hermetic pans
*4 222-13175-94
99.8 Ag hermetic pans 222-12826-92 Ag hermetic attachment
*5 346-68518-91
99.7 Al hermetic pans 222-12809-91 Hermetic attachment
(for the DSC autosampler)
(for the DSC )
*6 346-68796-91
50.00 100.00 150.00 Hermetic attachment
Temp (°C) Al hermetic pans 222-12804-91 (for the DSC autosampler)
(for the DTG)
Measurement of the Moisture Content *7 222-13073-91 Al pressure-proof pans
of PET Fiber (using a quartz crucible) Al pressure-proof pans 222-12915-91 attachment
Differential Thermal Analyzer DTA-50 DTA
High Temperature Heat Flux DTA, provides Quantitative
Calorimetry Measurements
Handpress SSP-10A Sealer adapter for stainless steel (SUS)
With a unique high sensitivity dumbbell detector, which has an extremely low heat capacity, high
sensitivity and excellent versatility, the DTA-50 offers the high sensitivity performance of the DSC (P/N 200-64175) pressure-proof pan (P/N 222-01875-91)
system. It is the ideal instrument for characterizing materials such as glass or ceramics.
Used to press 5 MPa Stainless steel (SUS) Used to seal 5 MPa Stainless steel (SUS)
Specifications pressure-proof pans ⑨. pressure-proof pans ⑨.
Temperature range Ambient to 1500°C
Measuring range 0.2 to 1000 V / 0.2 mW~
Atmosphere Air and inert gas
Dimensions and weight W: 173 x D: 550 x H: 550 (mm), 23 kg
Power supply AC 100 V, 120 V, 230 V, 1200 VA, 50/60 Hz
