Cylindrical Cell, single cell

Two polished windows.
Closed by PTFE stopper, providing a liquid-tight seal.
10 & 20 mm cell closed by a single PTFE stopper
50 & 100 mm cell closed by two PTFE stoppers
Internal diameter = 19mm

Light Maximum External Dimension
path /mm Vol/µL (Dia. x L) / mm Quartz cell Glass cell
10 2800 22 x 12.5 226-85701-10 226-85711-10
20 5600 22 x 22.5 226-85701-20 226-85711-20
10mm Cylindrical Quartz Cell,
50 14100 22 x 52.5 226-85701-50 226-85711-50 226-85701-10
100 28200 22 x 102.5 226-85701-00 226-85711-00

Standard Fluorescence Cell with PTFE Lid, Single cell
Open top, with non-sealing PTFE cover.
Four windows and base polished.

Light Maximum External Dimension
path /mm Vol/µL (L x W x H) / mm Quartz cell Glass cell
5 1700 7.5 x 12.5 x 45 226-85801-05 226-85811-05
10 3500 12.5 x 12.5 x 45 226-85801-10 226-85811-10
20 7000 22.5 x 12.5 x 45 226-85801-20 226-85811-20 10mm Fluorescence Cell,
40 14000 42.5 x 12.5 x 45 226-85801-40 226-85811-40 226-85801-10

Micro Fluorescence Cell with PTFE Lid, Single cell
Four windows and base polished.
Comes with non-sealing PTFE cover.
Base thickness - 3mm
Suitable for use with all standard cell holders.
Light Maximum External Dimension
path /mm Vol/µL (L x W x H) / mm Quartz cell
Micro Fluorescence Cell,
10 700 12.5 x 12.5 x 45 226-85901-10
226-85901-10

Flow cells

Two polished windows, long aperture.
Path lengths of 0.5mm or less incorporate by-pass tubes to avoid back pressure
and assist laminar flow through the sample compartment.
M6 Screw-in connections.
Profiled sample compartment to optimize flow characteristics, reduces carry over
and bubble retention.

Light Maximum External Dimension
path /mm Vol/µL (L x W x H) / mm Z Height Quartz cell
0.1 41 12.5 x 12.5 x 45 15 226-89021-01
0.2 47 12.5 x 12.5 x 45 15 226-89022-02
0.5 95 12.5 x 12.5 x 45 15 226-89023-05
1 120 12.5 x 12.5 x 45 15 226-89024-10 0.5mm Flow Cell,
226-89023-05
