Connection Diagrams

GC / FID

GC/FID Solution 2 (Carrier Gas = Make-Up Gas)

Carrier = Make-Up Gas
Hydrogen
Product Part No. Qty
Air
GC Triple Filter 226-50751-00 1
Hydrocarbon/ 226-50750-00 2
Moisture Filter
FID 3 Position Base 226-50773-00 1
plate
Kit Part Number 226-50730-00

LC/MS

Product Part No. Qty

High-Flow Base plate LC High Flow 226-50760-00 1
Hydrocarbon
Supply Gas Filter Bundle
MS Particle Filter 226-50794-01 1
High Flow Base
plate 226-50775-01 1
Kit Part Number 226-50720-00

Product Part No. Qty
High Flow
High-Flow Base plate LC Moisture Filter 226-50762-00 1
Supply Gas Bundle
Particle Filter 226-50794-01 1
MS High Flow Base
plate 226-50775-01 1
Kit Part Number 226-50722-00

Product Part No. Qty
High-Flow Base plate LC High Flow
Supply Gas Hydrocarbon/ 226-50764-00 1
Moisture Filter
Bundle
MS Particle Filter 226-50794-01 1
High Flow Base 226-50775-01 1
plate
Kit Part Number 226-50724-00
