Easy and Leak-tight Replacement

As long as there is no filter
cartridge connected, the
spring-loaded check valves block
the gas stream automatically.

Installing the filter

The design of the Shimadzu Super-Clean Gas Filter makes it possible to replace filter cartridges quickly and easily without any tools.
Spring-loaded check valves seal when a cartridge is removed and open only when a new cartridge has been locked in place, which
prevents contamination of the system during the replacement process.
Swagelok connector can be connected directly to the Shimadzu gas supply pipe, ensuring a leak free and completely clean gas line

Unique Body Design

A plastic body helps with checking the indicators and replacing the filter cartridges. However, it also allows contaminants to diffuse
into the instrument and cause helium to leak. To address this issue, the Shimadzu Super-Clean Gas Filter has been designed to pack
the absorbents in glass inside the plastic body, thereby preventing diffusion.

Plastic body
Indicator
Plastic body
Glass inside

Contaminants
Helium

Other filter with plastic body Shimadzu Super-Clean Gas Filter

Easy-to-read Indicator

The Shimadzu Super-Clean Gas Filter is designed with an easy-to-
read indicator. It changes color when the absorbent is saturated,
indicating when filter cartridges should be replaced.

Before using If absorbent is saturated,
the indicator changes color
