Syringe for Gas Analysis

Luer Lock Needle Style

Syringe Volume PTFE Tipped Plunger P/N Replacement Plunger P/N
1 mL √ 221-54778-01 221-54778-11
5 mL √ 221-54778-02 221-54778-12
10 mL √ 221-54778-03 221-54778-13
25 mL √ 221-54778-04 221-54778-14
50 mL √ 221-54778-05 221-54778-15
100 mL √ 221-54778-06 221-54778-16

Luer Lock Needle 1

Needle Length (mm) Needle Gauge Needle OD (mm) Needle Tip Qty P/N
50 23 0.63 Bevel 5 221-54778-51
50 19 1.07 Bevel 5 221-54778-52
50 14 2.1 Bevel 5 221-54778-54
OPEN CLOSED

Syringe Valve
2
Diag. # Syringe Volume Description Qty P/N
1 5 mL to 2 L Push Button Valve for Luer Lock Needle 1 221-54778-49
2 50 μL to 2 L Push Button Valve for Luer Lock Needle and Tip Syringe 1 221-54778-50

OPEN CLOSED
Removable Needle Style
Gastight syringes with a capacity of milliliter quantity level. The needle is 30mm long and is of a screw-in type, which ensures an easy
exchange.

Description Syringe Volume P/N Replacement Needle P/N
MS-GAN025 0.25 mL 670-12504-28
MS-GAN050 0.5 mL 670-12504-29
MS-GAN100 1 mL 670-12504-30
670-12504-85 (5 pcs)
MS-GAN250 2.5 mL 670-12504-31
MS-GAN500 5 mL 670-12504-32
MS-GANX00 10 mL 670-12504-33

PIN Style Microsyringe
Plunger-in-needle style. The plunger goes into the needle tip to eliminate dead volume. Ideal for highly precise analysis of micro-
volume samples.

Description P/N Syringe Volume
0.5BR-7 670-12510-71 0.5 μL
1BR-7 670-12510-72 1 μL
5BR-7 670-12510-73 5 μL

Pg C-63
