Page 36 - Solutions for Plastic Evaluation

n

Fourier Transform Infrared
Product Information
Spectrophotometer
Evaluation of Raw Materials

Evaluation of Plastic Materials Analysis of Plastic Samples by FTIR

Many different types of information can be obtained from plastic samples using FTIR systems, such as information for checking raw
materials, the composition of plastic pellets or powders, bonding modes, isotope ratios, copolymer composition ratios, molecular
orientation, and information for analyzing foreign matter or other defects. Since FTIR allows analyzing samples easily and quickly, and also
allows analyzing micro areas and surfaces, it is especially useful for analysis and testing in various plastic product manufacturing processes.

Features of the Shimadzu IRAffinity-1
Evaluation of Raw Materials • Higher sensitivity and performance than general purpose systems
Fourier Transform Infrared Spectrophotometer

• IRsolution software is easy to operate and offers sophisticated functionality
• Expanding range of applications
This attractive and compact Fourier transform infrared spectrophotometer features a
dynamic alignment mechanism that keeps the interferometer continuously optimized
and a built-in dehumidifier that ensures easy maintenance. It offers an S/N ratio of IRAffinity-1
Product Evaluation to-peak), maximum resolution of 0.5 cm , and a compact design. In addition, the
30,000:1 (given 4 cm resolution, 1 minute accumulation, near 2100 cm , and peak-
-1
-1
-1
IRsolution high-functionality, high-operability software and analysis support programs
(Contaminant Analysis Program and Pharma Report Program) ensure data processing
and postrun analysis can be accomplished easily.
Features of the Shimadzu IRPrestige-21
Fourier Transform Infrared Spectrophotometer
Product Information • High sensitivity and high functionality IRsolution High-Functionality Software
• High reliability
• Measurement range from near infrared to far infrared
• IRsolution high-functionality, high-operability software
High-throughput optics, with features such as a high-energy ceramic light source,
temperature-controllable high-sensitivity DLATGS detector, and gold-coated mirrors,
achieves high S/N ratios above 40,000:1 (given a 4 cm resolution, 1 minute
-1
accumulation, near 2100 cm , and peak-to-peak). In addition, an advanced dynamic
-1
alignment (ADA) mechanism keeps the interferometer continuously optimized and
a built-in dehumidifier ensures easy maintenance. A wide measurement range,
from near infrared to far infrared, and a wide assortment of accessories expand the
possible range of applications. In addition, the IRsolution high-functionality, high-
operability software and analysis support programs (Contaminant Analysis Program
and Pharma Report Program) ensure data processing and postrun analysis can be
accomplished easily.

Near Infrared Spectrum of Octanoic Acid
IRPrestige-21
(tracking changes in hydrogen bonds due to heat)

36
