Sum parameter – Total Organic Carbon
TOC – Determination in diluted hydrofluoric
acid
SCA-130-310
Hydrofluoric acid is the only acid that attacks ■ TOC determination
glass (glass etching). Because of this In the following measurement, a 4%
chemical property, it plays a distinct role in hydrofluoric acid was manually diluted to 1:10
several industrial processes, for instance in with water and measured using the TOC-
the manufacturing of solar cells and wafers L CPH. Given the acidity of the hydrofluoric
as well as in microchip production. acid, the IC content can be neglected. With
Hydrofluoric acid is the most widely used regard to the dilution, the solution was slightly
etching agent in the semiconductor industry. acidified and sparged for 3 minutes. The
NPOC was subsequently determined by
means of combustion oxidation.
An aliquot of the sample is injected onto a hot
(680 °C) platinum catalyst. The organic
substances are converted to CO 2 and
detected via an NDIR detector.
■ Calibration
Due to mostly working in a small measuring
range, calibration was carried out in a range
of 0.25 mg/L – 5.0 mg/L. For dilutions, the
When carrying out etching processes, it is automatic dilution function of the TOC-L
important to ensure that the etching agent system was applied. The injection volume
used will etch the respective layers and not was 150 µL respectively.
leave any contaminants.
This raises questions on the impurities of Kal. Kurve
etching agents, where both the purity of the 69,047
60
starting acid and that of the etching solutions 50
after the etching process are of interest. 40
Fläche
To determine the degree of contamination, 30
the TOC parameter is particularly suitable, as 20
it is a sum parameter that detects all organic 10
carbon compounds. 0 0 1 2 3 4 5 5,5
Konz[mg/L]
Figure: Calibration curve, TC 5 mg/L.
