Application   No. G290
    News



            „  Class2
            Due to the large number of components in the Class 2   the Class 2 standard solution Mixture A chromatogram
            standard solution, it was separated into two mixtures:   be 1.0 or greater.
            A and B. Respective measurement results are shown in   Fig.3 shows that, using the Restek SH-Rxi-624SilMS
            Fig.3 and Fig.4. Procedure A requires that the     low-bleed column, the specified peaks are completely
            resolution for acetonitrile and methylene chloride in
                                                               separated, with a resolution of 2.4.
                                                             11 12 13 14
                                                                                  1:  Methanol
                     3   4   5  6  7       8                        15
                                                                                  2: Acetonitrile
                                                                                  3:  Methylene chloride (DCM)
                                                                                  4: trans-1,2-Dichloroethylene
                                                                                  5: cis-1,2- Dichloroethylene
                                                                                  6: Tetrahydrofuran
                                                                                  7: Cyclohexane
                                                                                  8: Methylcyclohexane
                  1                                                               9: 1,4-Dioxane
                                                                                  10: Toluene
                                                                                  11: Chlorobenzene
                     2
                                                                                  12: Ethylbenzene
                                                                                  13: m,p-Xylene
                                             9                                    14: o-Xylene
                                                                                  15: Cumene
             0   2.5   5.0   7.5   10.0   12.5  15.0   17.5   20.0  22.5  25.0  27.5  30.0  32.5  min


                                                    3   4
                                       Resolution 2.4
                                      1
                                               2




                                 2.0   3.0   4.0   5.0   6.0  min

                               Chromatogram of WATER-SOLUBLE ARTICLES Class 2A Standard Solution by Procedure A




                        1             5                               8
                                                       7
                                                                                    1:  Hexane
                                                                                    2: Nitromethane
                                                                                    3: Chloroform
                                                                                    4: 1,2-Dimethoxyethane
                                                                                    5: Trichloroethene
                                                                                    6: Pyridine
                                                                                    7: Methylbutylketone
                             3                                                      8: Tetraline
                                                   6

                          2
                                 4


                     5.0     10.0    15.0    20.0    25.0    30.0    35.0     min

                               Chromatogram of WATER-SOLUBLE ARTICLES Class 2B Standard Solution by Procedure A


                                                                                                      First Edition: Jun. 2017
