Options Used for Measurements

Chemicals Foods

Film Thickness Measurement Quantitation of Amount of Fat in Foods

Interference wave patterns sometimes occur when light passes Recently, fat-modified products have become widely available. The Gerber method and Roese-Gottlieb method are usually used
through a transparent film. The film thickness of a sample can be Options Used for Measurements to determine the fat level in milk, a process that requires a long measurement time. Therefore, the measurement was conducted
determined by using the interference waveform. The black line is for using a combination of the spectral reflectance method and multivariate analysis. The figure below shows the spectral reflectance
polyvinylidene chloride film, the red line is for polycarbonate film, and Film Holder spectrum of a milk sample, which was placed in a screw tube and measured by the UV-3600i Plus and ISR-603. The quantitation
the blue line is for polypropylene film. of the amount of fat was conducted by generating a calibration curve using the spectrum and fat amount data.
The values of 9.9 m, 49.3 m, and 59.5 m were calculated from the R%
interference waveforms using the optional film thickness calculation. 70.0 Amount of Fat Shown Estimation Results Estimation Estimation Results
Fat Amount 2.0 (g/200 mL) on the Milk Using Multiple Results Using Support
Note: The refractive index of the sample must be entered in order to 60.0 Samples Carton Package Regression Using PLS Vector Regression
perform the calculation. Fat Amount 1.0 (g/200 mL) (g/200mL) Analysis Methods Regression Methods Analysis Methods
st
Creamy 3 (1 time) 9.5 8.87 (6.6%) 9.57 (0.7%) 9.72 (2.3%)
40.0
Creamy 3 (2 nd time) 9.5 8.89 (6.4%) 9.67 (1.6%) 9.47 (0.3%)
Regular 3 (1 st time) 7.6 8.04 (5.8%) 8.40 (10.5%) 7.88 (3.7%)
Film Thickness Calculation Software Regular 3 (2 nd time) 7.6 7.59 (0.1%) 7.71 (1.4%) 7.31 (3.8%)
20.0
This software calculates the film thickness from the Low Fat 3 (1 st time) 2.0 2.24 (12.0%) 1.78 (11.0%) 2.01 (0.5%)
measured spectrum using the interference interval Fat Amount Low Fat 3 (2 nd time) 2.0 2.36 (18.0%) 1.72 (14.0%) 1.86 (7.0%)
0.2 (g/200 mL)
method. (An input of the refractive index of the 0.0 1000.0 1200.0 1400.0 1600.0 1800.01900.0
sample is required to calculate the film thickness.) nm
The interference method calculates the film
thickness from the distance between the peaks of Textiles
the interference waveform (Baray). You can set the
detection parameters for the peak (Baray) and the Diffuse Reflectance Measurement of Various Fabrics
incident angle and wavelength range for the film
thickness calculation. The diffuse reflectance spectra of various textiles were measured in the
visible region using the ISR-603 integrating sphere attachment.
The blue line indicates a blue fabric and the red line indicates a red fabric.
The blue fabric mainly reflects short-wavelength blue light, so it appears
blue, while the red fabric mainly reflects long-wavelength red light, so it
appears red.
The combination of the UV-3600i Plus and the ISR-603 is ideal for
Pharmaceuticals
measuring color. Also, the optional color measurement software enables
colors to be calculated and displayed in a variety of color space models.
Measurement of Anhydrous Caffeine in Cold Remedy
Anhydrous caffeine is included in cold medicines. The figure below shows the results of measuring anhydrous caffeine using a Options Used for Measurements
powdered sample holder. It enables volumes as small as 0.16 mL to be measured easily.
The combination of the UV-3600i Plus, ISR-603, and powdered sample holder is ideal for the diffuse reflectance measurement Film Holder Color Calculation Software
of powder. Software that calculates the color value of a measurement from the measured
spectrum. You can display a graph of the chromaticity coordinates xy in the XYZ
Options Used for Measurements colorimetric system or a graph of the luminosity index/color coordinates in CIELAB.
Contains the main calculation items for the XYZ colorimetric system, CIELAB,
Powdered Sample Holder CIELUV, Munsell colorimetric system, mentality, yellowness, whiteness, and color
Powdered Sample Holder difference.
You can calculate items related to JIS and ASTM colors. *
For various calculations, you can set the measurement illuminant and observation
viewing angle.
ISR-603 Integrating Sphere UPF Calcuration Software
Attachment
Other Software to calculate UPF (ultraviolet shielding factor) from a measured spectrum.
UPF, UVA, UVB, UV block rate, UV block rate (UVA, UVB) can be calculated.
ISR-603 Integrating Sphere Attachment You can calculate related items of JIS, DIN, BS, AATCC, AS/NZAA, GB/T. *
* Please contact us for details on the corresponding standard.
