Micro Cell Unit
(P/N 204-27125-41)
This allows measuring sample quantities of only 400 L. It is placed in the same cell holder as a regular 10
mm standard cell polished on four sides. However, it cannot be used with a sample elevation stage (P/N
204-04811).

Cell Polished on Four Sides (Fused Quartz)
(P/N 200-34441)
Non-Fluorescent Cell (Special Fused Quartz)
(P/N 200-34594-03)
Quartz cells with four sides polished absorb a small amount of light near 260 nm, which results in a slight
fluorescence near 400 nm. Therefore, this non-fluorescent cell with special fused quartz is recommended for
measuring low concentration samples with excitation near 260 nm. Non-Fluorescent Cell

LC Flow Cell Unit (12 L Cell)
(P/N 204-05566-41)

With this attachment, the RF-6000 can be used as a highly sensitive spectral fluorescence monitor for high
performance liquid chromatography. The excitation and fluorescence wavelengths are freely selectable,
permitting selective detection. In addition, it allows you to record spectra with solvent delivery paused, which
is very useful for identifying chromatography peaks. A rectangular quartz micro flow cell with minimized light
scattering and a 12 L capacity is used.

Note: Requires a separate optional front cover (P/N 207-20490).

LC Flow Cell Unit (120 L Cell)
(P/N 204-06249-41)
This LC flow cell unit is for analyzing catecholamine. A rectangular quartz micro flow cell with minimized
light scattering, two reflective sides, and a 120 L capacity is used.
Note: Requires a separate optional front cover (P/N 207-20490).

Filter Set
(P/N 204-04691)
Set of seven filters; includes IHU-310, U-340, L-42, Y-50, O-56, R-60, and B-390 filters

8 mm Diameter Test Tube Holder
(P/N 204-05853-41)
Holds 8 mm diameter test tubes. (The minimum sample volume required is 400 L.)
Test tube size: 8 mm OD, between 45 mm and 100 mm long

12 mm Diameter Test Tube Holder
(P/N 204-03293-41)

Holds 12 mm diameter test tubes.
Test tube size: 12 mm OD, between 60 mm and 100 mm long
