Page 13 - Shimadzu ICPMS-2030 Series

Peripheral Equipment / Application Systems

For automatic analysis of 60 samples Cooling Water Circulator Set
AS-10 Autosampler (P/N 211-92962-41)
(P/N 211-93680-58) Size: W377 × D500 × H615 mm
Multiple samples can be analyzed successively. The Power supply: Single-phase 200 V, 50/60 Hz, 2 kVA
turntable results in a short path length for sample Weight: 43 kg
injection, which can reduce the rinse time. Note: Used to cool the main unit.
Note: Requires a Chiller Connection Kit (P/N 211-93827-41).
Vials: 60 15-mL vials
8 50-mL vials
Size: W290 × D508 × H300 mm (excluding arm)
Power supply: Single-phase 100–240 V, 50/60 Hz, 50 VA
Note: Requires a Power Cord.
Note: An additional rinsing port is optional (There is no automatic solvent supply).
Rinsing Port Expansion Kit for AS-10 (P/N 211-94072-41).
Tap Water Connection Kit
(P/N 211-90558-41)
For automatic analysis of 240 samples This is required if using tap water to cool the main ICPMS-2030 unit.
ASX-560 Autosampler Note: Requires a Copler for Tap Water (P/N 035-60942-15).
(P/N 211-94230-01)
Vials:
10 50-mL vials (standard samples) or 240 14-mL vials
160 20-mL vials (rack sold separately) Noise Absorbing Box, SV65 Large
(P/N 225-27850-07)
84 50-mL vials (rack sold separately)
Size: W580 × D550 × H620 mm Note: Requires Noise Reduction Box Connection Kit (P/N 211-93825-41) for Noise
(include sample probe) Reduction Box for Rotary Pumps.
W90 × D180 × H60 mm
(rough dimensions of power supply unit)
Power supply: 100–240 V AC, 47-63 Hz, 1.9 A
Weight: 11.7 kg (main unit) Exhaust Duct Connection Adapter
Note: Requires an ASX Connection Kit ICPMS-2030 (P/N 211-94476-41). (P/N 211-93832-41)
Needed when connecting a exible duct made of stainless steel having an
internal diameter of 100 mm to the exhaust duct of the plasma stand. For
details, please refer to the “Pre-Installation Requirements.”
For automatic analysis of 120 samples
ASX-280 Autosampler
(P/N 211-94412)
HFS-5 Hydro uoric Acid Sample Injection System
Vials:
10 50-mL vials (standard samples) or 120 14-mL vials (P/N 211-93828-41)
80 20-mL vials (rack sold separately) This system includes a torch, chamber, extension tube, nebulizer, drain,
42 50-mL vials (rack sold separately) and their corresponding accessory parts.
Size: W360 × D550 × H660 mm Used to directly inject samples that contain hydro uoric acid. The
(include sample probe) nebulizer, chamber, and drain system are made using uoropolymer
W90 × D180 × H60 mm materials and the injector unit on the torch is made using alumina.
(rough dimensions of power supply unit)
Power supply: 100–240 V AC, 47-63 Hz, 1.9A
Weight: 8.1 kg (main unit)
Note: Requires an ASX Connection Kit ICPMS-2030 (P/N 211-94476-41). Organic Solvent Injection System
To introduce organic solvents, a mixture of argon and oxygen gases (70%
Ar and 30% O 2 ) is injected into the interface unit to prevent precipita-
Automatic Internal Standard Addition Kit tion of carbon (C) by the organic solvent. This system includes a
(P/N 211-95010-41) Quadruple Torch for Organic Solvents, ICPMS, drain, and their
This kit is used for in-line mixing of measurement sample and internal corresponding accessory parts. Please inquire about the type of organic
standard solutions and introducing the mixtures into the ICP system. solvent supporting this system.

LC–ICP–MS System LA–ICP–MS System (Laser Ablation ICP–MS System)
It can be used as the LC–ICP–MS system by connecting the ICPMS-2030 and The LA–ICP–MS system can be set by combining the ICPMS-2030 and
the Prominence™ inert LC system online. other companies’ laser ablation equipment.
Please contact us for details. Please contact us for details.

13
