Page 147 - Shimadu Consumables Catalog

Solvent Kits

Solvent Safety Caps Kit

Features PTFE Filter Membrane
PTFE Insert
Minimize release of solvent odors
Polypropylene Spin Collar
One-way emission control valve allows air to enter the PTFE Air Inlet Valve with SS spring
reservoir as solvent is removed and elastomer o-ring (EPDM)

Valve opens at a low 0.07psi to minimize back pressure

Part number Description Consists of
1 226-50318-00 4 Ports bottle cap, 1 pc -
2 226-50319-00 2 Ports Bottle Cap, 1 pc -
3 226-50315-01 Plug, ¼-28, Virgin PTFE, 1pc -
4 226-50316-01 Tubing Connection, 1/8” OD tubing, Blue Polypro- -
pylene fitting, Yellow Tefzel ferrule, 1pc
5 226-50318-01 4 Ports Bottle Caps Kit 226-50315-00 Plug, ¼-28, Virgin PTFE, 2 pcs
Tubing Connection, 1/8” OD tubing, Blue Poly-
226-50316-00
propylene fitting, Yellow Tefzel ferrule, 4 pcs
226-50318-00 Safety Bottle Cap, 1pc
226-50319-01 2 Ports Bottle Caps Kit 226-50315-01 Plug, ¼-28, Virgin PTFE, 1 pc s
6 Tubing Connection, 1/8” OD tubing, Blue Poly-
226-50316-02
propylene fitting, Yellow Tefzel ferrule, 2 pcs
226-50319-00 Safety 2 Ports Bottle Cap, 1pc

1 2

3 4

5 6
